Data Sheet
October 7, 2013
KW010/015/020/025 Series Power Modules:
36
– 75Vdc Input; 1.2 to 5.0Vdc Output; 10 to 25A Output current
LINEAGE
POWER
3
Electrical Specifications
(continued)
Parameter
Device
Symbol
Min
Typ
Max
Unit
Output Voltage Set-point
A
V
O, set
4.93
5.0
5.08
V
dc
(V
IN
=V
IN, min
, I
O
=I
O, max
, T
A
=25°C)
F
V
O, set
3.25
3.3
3.35
V
dc
G
V
O, set
2.46
2.5
2.54
V
dc
Y
V
O, set
1.77
1.8
1.83
V
dc
M
V
O, set
1.48
1.5
1.53
V
dc
P
V
O, set
1.18
1.2
1.22
V
dc
Output Voltage
All
V
O
-3.0
+3.0
% V
O, set
(Over all operating input voltage, resistive load,
and temperature conditions until end of life)
Adjustment Range
All
V
O,adj
-20.0
+10.0
% V
O, set
Selected by an external resistor
Output Regulation
Line (V
IN
=V
IN, min
to V
IN, max
)
A, F, G
0.1
% V
O, set
Y, M, P
2
mV
Load (I
O
=I
O, min
to I
O, max
)
A, F, G
0.1
% V
O, set
Y, M, P
2
mV
Temperature (T
ref
=T
A, min
to T
A, max
)
All
1.0
% V
O, set
Output Ripple and Noise on nominal output
(V
IN
=V
IN, nom
,I
O
= I
O, max
, T
A
=T
A, min
to T
A, max
)
RMS (5Hz to 20MHz bandwidth)
A, F, G, Y
25
mV
rms
Peak-to-Peak (5Hz to 20MHz bandwidth)
75
mV
pk-pk
RMS (5Hz to 20MHz bandwidth)
M, P
33
mV
rms
Peak-to-Peak (5Hz to 20MHz bandwidth)
100
mV
pk-pk
External Capacitance
All
C
O, max
0
10,000
μF
Rated Output Current
A
I
O, Rated
0
10
A
dc
F
I
O, Rated
0
15
A
dc
G
I
O, Rated
0
20
A
dc
Y
I
O, Rated
0
25
A
dc
M
I
O, Rated
0
25
A
dc
P
I
O, Rated
0
25
A
dc
Output Current Limit Inception (Hiccup Mode )
All
I
O
, lim
106
120
146
%I
O, Rated
(V
O
= 90% of V
O, set
)
Output Short-Circuit Current
All
I
O, s/c
3
A
rms
(V
O
≤250mV) ( Hiccup Mode )
