GE Industrial Solutions JRW017-040-060-065-070 Series - Manual (Page 24)

Data Sheet
June 14, 2010
JRW017-070 Series Power Modules DC-DC Converters
36-75Vdc Input; 1.2Vdc to 12Vdc Output
Document No: DS03-120 ver 1.25
PDF name: JRW017A0B.pdf
Ordering Information
Please contact your Lineage Power Sales Representative for pricing, availability and optional features.
Table 3. Device Code
Product codes Input Voltage
Output
Voltage
Output
Current
Efficiency Connector
Type
Comcodes
JRW017A0B1 48V (36-75Vdc) 12V 17A 92% Through hole 108967142
JRW040A0A1 48V (36-75Vdc) 5V 40A 92% Through hole 108965385
JRW060A0F1 48V (36-75Vdc) 3.3V 60A 91% Through hole 108965393
JRW065A0G1 48V (36-75Vdc) 2.5V 65A 90% Through hole 108965401
JRW065A0Y1 48V (36-75Vdc) 1.8V 65A 87% Through hole 108965435
JRW070A0M1 48V (36-75Vdc) 1.5V 70A 86 % Through hole 108965419
JRW070A0P1 48V (36-75Vdc) 1.2V 70A 84 % Through hole 108965427
JRW017A0B1Z 48V (36-75Vdc) 12V 17A 92% Through hole CC109104618
JRW040A0A1Z 48V (36-75Vdc) 5V 40A 92% Through hole CC109107422
JRW060A0F1-HZ 48V (36-75Vdc) 3.3V 60A 91% Through hole CC109107455
JRW065A0G1-HZ 48V (36-75Vdc) 2.5V 65A 90% Through hole CC109107471
Table 2. Device Options
Option Device Code Suffix
Negative remote on/off logic 1
Auto-restart 4
Pin Length: 3.68 mm ± 0.25mm (0.145 in. ± 0.010 in.) 6
Case pin (Available with Baseplate option only)* 7
Basic Insulation -B
Base Plate option -H
Output current share (Parallel Operation)* -P
RoHS Compliant -Z
*Note: The case pin and Ishare pin use the same pin location such that both options cannot be specified
simultaneously.
