GE
Datasheet
SHHN000A3 Series; DC-DC Converter Power Modules
9Vdc – 36Vdc input; +15V, -15V Dual Output, 0.3A 9W Output
December 6, 2013
©2013 General Electric Corporation.
All rights reserved.
Page 3
Electrical Specifications (continued)
Parameter Device Symbol Min Typ Max Unit
Output Voltage Set-point 1
+15.0 V
O1
V
O1, set
-1.5% +1.5% %V
0
(V
IN
=9 to 36V
dc
, I
O
=I
O, max
, T
A
=25°C)
Output Voltage Set-point 2
-15.0 V
O2
V
O2, set
-1.5% +1.5% %V
0
(V
IN
=9 to 36V
dc
, I
O
=I
O, max
, T
A
=25°C)
Output Voltage Accuracy
All V
O1, 02
-3.0 ⎯ +3.0 % V
O, set (Over all operating input voltage, resistive load, and temperature
conditions until end of life)
Output Regulation
Line (V
IN
=V
IN, min
to V
IN, max
) All ⎯ 0.05 0.3 % V
O, set
Load (I
O
=10% to I
O, max
) All ⎯ 0.05 0.3 % V
O, set
Temperature (T
ref
=T
A, min
to T
A, max
) All ⎯ ⎯ 1.0 % V
O, set
Cross Regulation (10-100% Load on each output)** All 5 % V
O, set
Output Ripple and Noise on nominal output
Measured with 10uF Tantalum||1uF ceramic
(V
IN
=24 V
dc
, I
O
=100%I
O, max
, T
A
=25°C)
RMS (5Hz to 20MHz bandwidth)
All
⎯ 50 mV
rms
Peak-to-Peak (5Hz to 20MHz bandwidth) ⎯ 200 mV
pk-pk
External Capacitance All C
O, max
0 ⎯ 470 μF
Output Current -1 All I
o1
0 ⎯ 0.3 A
dc
Output Current - 2 All I
o2
0 ⎯ 0.3 A
dc
Output Current Limit Inception (Hiccup Mode) All I
O, lim
0.6 A
dc
Output Short-Circuit Current
All I
O, s/c
⎯ 0.4 A
rms
V
O
≤ 250 mV @ 25°C
Efficiency
V
IN
=24V
dc
, T
A
=25°C, I
O
=I
O, max
All η - 84 ⎯ %
Switching Frequency (Fixed)
All f
sw
⎯ 300 ⎯ kHz
V
IN
=9 to 36V
dc
and I
O
= I
O, max
Dynamic Load Response
( ΔI
O
/ Δt=0.1A/μs, V
IN
=24 V
dc
, T
A
=25°C)
Load Change from I
O
= 50% to 75% or 25% to 50% of I
O,max
:
Peak Deviation All V
pk
⎯ 3.0 ⎯ % V
O, set
Settling Time (Vo<10% peak deviation) All t
s
⎯ 800 ⎯ μs
* *Operation at 0A will not damage module
Isolation Specifications
Parameter Symbol Min Typ Max Unit
Isolation Capacitance C
iso
⎯ 1000 ⎯ pF
Isolation Resistance R
iso
200 ⎯ ⎯ MΩ
I/O Isolation Voltage – (1minute at 1mA) All ⎯ 1600 Vdc
