Datasheet
SHHN000A3 Series; DC-DC Converter Power Modules
9Vdc – 36Vdc input; +15V, -15V Dual Output, 0.3A 9W Output
December 6, 2013
©2013 General Electric Corporation.
All rights reserved.
Page 2
Absolute Maximum Ratings
Stresses in excess of the absolute maximum ratings will cause permanent damage to the device. These are absolute stress ratings
only, functional operation of the device is not desired at these or any other conditions in excess of those given in the operations
sections of the Datasheet. Exposure to absolute maximum ratings for extended periods can adversely affect the device reliability.
Parameter Device Symbol Min Max Unit
Input Voltage (Continuous) All V
IN
-0.3 40 Vdc
Transient (1s) – No damage All V
IN, trans
-0.3 50 Vdc
Operating Ambient Temperature All T
A
-40 85 °C
(see Thermal Considerations section)
Storage Temperature All T
stg
-55 125 °C
Altitude All 4000 m
I/O Isolation Voltage (100% factory Hi-Pot tested) All ⎯ 1600
\
Vdc
Electrical Specifications
Unless otherwise indicated, specifications apply over all operating input voltage, resistive load, and temperature conditions .
Parameter Device Symbol Min Typ Max Unit
Operating Input Voltage All V
IN
9 ⎯ 36 Vdc
Maximum Input Current All I
IN
1.3 Adc
(V
IN
=9 to 36V, I
O1
=I
O, max,
, I
O2
=I
O2 max,
)
Input No Load Current
(V
IN
= 24Vdc, I
O
= 0, module enabled)
V
O1,02
= ON I
IN,No load
30 mA
Input Stand-by Current
(V
IN
= 24Vdc, module disabled)
All I
IN,stand-by
9 mA
Inrush Transient All I
12
t 0.05 A 2 s
Input Reflected Ripple Current, peak-to-peak
(5Hz to 20MHz, 1μH source impedance; V
IN
=0 to 36V
,
I
O1
&02
= I
Omax
; See Test Configurations)
All 30 mAp-p
Input Ripple Rejection (120Hz) All 40 dB
