SMR2 Modbus User Manual
16
Bit position in Bit map
Bit Position in Bitmap Meaning Event code (Hex)
0 0 No Remote Trip
1 Remote Trip
6
1 0 Aux Switch Open
1 Aux Switch Closed C
2 0 No Low Trip Voltage Warning
1 Low Trip Voltage Warning
0E
3 0 No RAM Failure
1 RAM Failure
10
4 0 No ROM Failure
1 ROM Failure 11
5 0 No Rating Plug Missing
1 Rating Plug Missing
13
6 0 No Short Time Switch Change
1 Short Time Switch Change
14
7 0 No Long Time Switch Change
1 Long Time Switch Change 15
8 0 No Instant Switch change
1 Instant Switch change
16
9 0 No Module Switch/Type Change
1 Module Switch/Type Change
17
10 0 No Short Time Delay Switch Change
1 Short Time Delay Switch Change 18
11 0 No Long Time Delay Switch Change
1 Long Time Delay Switch Change
19
12 0 No Missing Module
1 Missing Module
12
