9 GFA Reset (In GFA module
only)
3008 Ground Fault delay 0-9 Normal
Mode
RO
_________
Test Mode
RW
Value second I 2 T
0 40ms No
1 120ms No
2 210ms No
3 310ms No
4 420ms No
5 420ms Yes
6 310ms Yes
7 210ms Yes
8 120ms Yes
9 40ms Yes
3009 Inst. Pickup 0-9 Normal
Mode--RO
_________
Test Mode
RW
Unsigned int
Refer to the table
Normal
Mode - RO
3010 Module Address 0 - 240
Test mode
RW
3011 Last Trip Data Bitmap
0 - 255
Normal
Mode--RO
_________
Test Mode
RW
3012 Control Byte Bitmap
0-255
Normal
Mode--RO
_________
Test Mode
RW
3013 Protection Multiplier 64-100 Normal
Mode --RO
_________
Test Mode
RW
64% 100%
3014 Neutral Protection 0-100 Normal
Mode
RO
_________
Test Mode
RW
0%, 50%, 100%
3015 Temperature Limit 0-100 degree
C
Normal
Mode
RO
_________
Test Mode
RW
3016 Product Reject Code Key 0 - 65535 RO
3017 Rating Plug Serial Number
high
0-9999 RO
3018 Rating Plug Serial Number
low
0-9999 Normal
mode - RO
