Page 13
GE
Data Sheet
EVK011A0B Series (Eighth-Brick) DC-DC Converter Power Modules
36–60Vdc Input; 12.0Vdc Output; 11A Output Current
Contact Us
For more information, call us at
USA/Canada:
+1 888 546 3243
, or +1 972 244 9288
Asia-Pacific:
+86.021.54279977*808
Europe, Middle-East and Africa:
+49.89.878067-280
India:
+91.80.28411633
www.ge.com/powerelectronics
May 15, 2013
©2012 General Electric Company. All rights reserved.
Version 1.1
Ordering Information
Please contact your GE Sales Representative for pricing, availability and optional features.
Table 1. Device Codes
Product Codes
Input Voltage
Output
Voltage
Output
Current
On/Off Logic
Connector
Type
Comcodes
EVK011A0B41Z
48V (36-60Vdc)
12V
11A
Negative
Through hole
150027164
EVK011A0B641Z
48V (36-60Vdc)
12V
11A
Negative
Through hole
150030268
Table 2. Device Options and Coding Scheme
