GE Industrial Solutions PicoTLynx 3A - Manual (Page 24)

GE
Data Sheet
PicoTLynx TM 3A: Non-Isolated DC-DC Power Modules
2.4Vdc –5.5Vdc input; 0.6Vdc to 3.63Vdc output; 3A Output Current
Contact Us
For more information, call us at
USA/Canada:
+1 888 546 3243 , or +1 972 244 9288
Asia-Pacific:
+86.021.54279977*808
Europe, Middle-East and Africa:
+49.89.74423-206
India:
+91.80.28411633
www.ge.com/powerelectronics
September 11, 2013 ©2013 General Electric Company. All rights reserved. Version 1.16
Ordering Information
Please contact your GE Sales Representative for pricing, availability and optional features.
Table 8. Device Codes
Device Code
Input
Voltage Range
Output
Voltage
Output
Current
On/Off
Logic
Sequencing Comcodes
APXH003A0X-SRZ 2.4 – 5.5Vdc 0.6 – 3.63Vdc 3A Negative No CC109113313
APXH003A0X4-SRZ 2.4 – 5.5Vdc 0.6 – 3.63Vdc 3A Positive No CC109113321
APXH003A0X-SRDZ 2.4 – 5.5Vdc 0.6 – 3.63Vdc 3A Negative No CC109158795
APTH003A0X-SRZ 2.4 – 5.5Vdc 0.6 – 3.63Vdc 3A Negative Yes CC109113338
APTH003A0X4-SRZ 2.4 – 5.5Vdc 0.6 – 3.63Vdc 3A Positive Yes CC109113346
APTH003A0X-SR 2.4 – 5.5Vdc 0.6 – 3.63Vdc 3A Negative Yes CC109147484
Table 9. Coding Scheme
TLynx
family
Sequencing
feature.
Input
voltage
range
Output
current
Output
voltage
On/Off logic Options ROHS Compliance
AP T H 003A0 X 4 -SR -D Z
T = with Seq.
X = w/o Seq.
H = 2.4 –
5.5V
3.0A X =
programmable
output
4 = positive
No entry =
negative
S = Surface
Mount
R =
Tape&Reel
D = 105C
operating
ambient, 40G
operating
shock as per
MIL Std 810F
Z = ROHS6
