Data Sheet
March 3, 2011
EVW020A0S6R0 Series Eighth-Brick Power Modules
36–75Vdc Input; 6.0Vdc Output; 20A Output Current
Document No: DS09-010 ver. 1.2
PDF name: evw020s6r0_ds.pdf
Ordering Information
Please contact your Lineage Power Sales Representative for pricing, availability and optional features.
Table 1. Device Codes
Product Codes
Input Voltage
Output
Voltage
Output
Current
On/Off Logic
Connector
Type
Comcodes
EVW020A0S6R041Z
48V (36-75Vdc)
6.0V
20A
Negative
Through hole
TBD
EVW020A0S6R041-HZ
48V (36-75Vdc)
6.0V
20A
Negative
Through hole
CC109151833
EVW020A0S6R0841-HZ
48V (36-75Vdc)
6.0V
20A
Negative
Through hole
CC109153680
EVW020A0S6R041-SZ
48V (36-75Vdc)
6.0V
20A
Negative
Surface mount
TBD
Table 2. Device Coding Scheme and Options
Characteristic
Definition
Form Factor
E
E = Eighth Brick
Family Designator
V
Input Voltage
W
W = Wide Range, 36V-75V
Output Current
020A0
020A0 =
0
20.0 Amps Maximum Output Current
Output Voltage
S6R0
S6R0 = Special output voltage 6.0V nominal
Omit = Default Pin Length shown in Mechanical Outline Figures
6
6 = Pin Length: 3.68 mm ± 0.25mm , (0.145 in. ± 0.010 in.)
8
8 = Pin Length: 2.79 mm ± 0.25mm , (0.110 in. ± 0.010 in.)
Omit = Latching Mode
4
4 = Auto-restart following shutdown (Overcurrent/Overvoltage)
Omit = Positive Logic
1
1 = Negative Logic
Omit = Standard open Frame Module
H
H = Heat plate, for use with heat sinks (not available with –S option)
S
S = Surface mount connections
Customer Specific
XY
XY = Customer Specific Modified Code, Omit for Standard Code
Omit = RoHS 5/6, Lead Based Solder Used
Z Z = RoHS 6/6 Compliant, Lead free
RoHS
Ra
ti
n
g
s
Op
ti
o
n
s
Character and Position
Pin Length
Action following
Protective Shutdown
On/Off Logic
Mechanical Features
