Data Sheet
March 3, 2011
EVW020A0S6R0 Series (Eighth-Brick) DC-DC Converter Power Modules
36–75Vdc Input; 6.0Vdc Output; 20A Output Current
* UL is a registered trademark of Underwriters Laboratories, Inc.
†
CSA is a registered trademark of Canadian Standards Association.
‡
VDE is a trademark of Verband Deutscher Elektrotechniker e.V.
§ This product is intended for integration into end-user equipment . All of the required procedures of end-use equipment should be followed.
¤ IEEE and 802 are registered trademarks of the Institute of Electrical and Electronics Engineers, Incorporated.
** ISO is a registered trademark of the International Organization of Standards
Document No: DS09-010 ver. 1.2
PDF name: evw020s6r0_ds.pdf
Features
 Compliant to RoHS EU Directive 2002/95/EC (-Z
versions)
 Compliant to ROHS EU Directive 2002/95/EC with
lead solder exemption (non-Z versions)
 Compliant to IPC-9592, Category 2, Class II
 High efficiency 92% at 6.0V
dc
full load (Vin=48V
dc
)
 Industry standard, DOSA compliant footprint
58.4 mm x 22.8 mm x 8.1 mm
(2.30 in x 0.9 in x 0.32 in)
 Wide input voltage range: 36-75 V
dc
 Tightly regulated output
 Constant switching frequency
 Positive remote On/Off logic
 Input under/over voltage protection
 Output overcurrent and overvoltage protection
 Over-temperature protection
 Remote sense
 No reverse current during output shutdown
 Output Voltage adjustment range: 5.0V
dc
to 7.0V
dc
 Wide operating temperature range (-40°C to 85°C)
 ANSI/UL * 60950-1, 2nd Ed. Recognized, CSA † C22.2
No. 60950-1-07 Certified, and VDE ‡ 0805-1
(EN60950-1, 2nd Ed.) Licensed
 CE mark meets 2006/95/EC directive §
 Meets the voltage and current requirements for ETSI
300-132-2 and complies with and licensed for Basic
insulation rating per EN60950-1
 2250 Vdc Isolation tested in compliance with IEEE
802.3
¤ PoE standards
 ISO ** 9001 and ISO 14001 certified manufacturing
facilities
Applications
 Automated Test Equipment
 Wireless PA Pre-amps
 Precision Instruments
Options
 Negative Remote On/Off logic (preferred)
 Over current/Over temperature/Over voltage
protections (Auto-restart) (preferred)
 Heat plate version (-H)
 Surface Mount version (-S)
 Trimmed pin lengths
Description
The EVW020A0S6R0, Eighth-brick low-height power module is an isolated dc-dc converters that can deliver up to
20A of output current and provide a precisely regulated output voltage of 6.0V
dc
over a wide range of input voltages
(V
IN
= 36 - 75V
dc
). The modules achieve typical full load efficiency of 92%. The module offers wide output voltage trim
(5.0V
dc
to 7.0V
dc
), allowing designers to use the module with a wide variety of output LDOs for final load voltage. The
open frame modules construction, available in both surface-mount and through-hole packaging, enable designers to
develop cost and space efficient solutions. Standard features include remote On/Off, remote sense, output voltage
adjustment, overvoltage, overcurrent and overtemperature protection.
RoHS Compliant
