Remote HMI Software
50
8
NOTE: When installing a Remote HMI prior to the switchgear arrival, this step cannot be
performed. In this situation, a System Archive must be installed. See
for instructions.
8.2 Multiple lineups
The Remote HMI software allows the user to quickly navigate between multiple Entellisys 4.0
Lineups. It is important to note that HMI can only annunciate alarms from the current Lineup
which the HMI is connected. Alarms from all other configured lineups are not recognized until
the user connects to that lineup.
Highlights
• Available only on remote interactive or remote view HMI software
• View, edit and control up to 25 lineups
User Permissions
All users have permissions to add, change or delete Lineups
Offline Mode
If the Entellisys HMI software is configured for offline mode for any of the lineups, none of the
configured lineups will connect. (See
)
HMI Events
When logging into the system, the HMI will log an event “Switched to
will also log current time zones of the user’s PC running the Remote HMI software and the lineup
CPUs.
NOTE: Time zone differences between a remote HMI and the lineup will cause timestamp
differences between CPU and any local HMI events. Will not affect events on CPU
8.3 Configuring Lineups
To configure a Lineup, login to the HMI and from the main menu, select “HMI Preferences.” Click
on the “Config Lineup”
