GE Industrial Solutions EQW012-020-023-025 Series - Manual (Page 25)

Data Sheet
October 5, 2013
EQW012/020/023/025 Series, Eighth-Brick Power Modules:
36 - 75Vdc Input; 1.2Vdc to 5Vdc Output; 12A to 25A Output
Document No: DS03-74 ver. 1.27
PDF name: EQW12-25.pdf
World Wide Headquarters
Lineage Power Corporation
601 Shiloh Road, Plano, TX 75074, USA
+1-800-526-7819
(Outside U.S.A.: +1-972-244-9428)
www.lineagepower.com
e-mail: [email protected]
Asia-Pacific Headquarters
Tel: +65 6593 7211
Europe, Middle-East and Africa Headquarters
Tel: +49 89 878067-280
India Headquarters
Tel: +91 80 28411633
Lineage Power reserves the right to make changes to the product(s) or information contained herein without notice. No liability is assumed as a result of their use or
application. No rights under any patent accompany the sale of any such product(s) or information.
Lineage Power DC-DC products are protected under various patents. Information on these patents is available at
www.lineagepower.com/patents .
© 2009 Lineage Power Corporation, (Plano, Texas) All International Rights Reserved.
Table 2. Device Options
Option Suffix*
Negative remote on/off logic 1
Short Pins: 3.68 mm ± 0.25 mm (0.145 in ±0.010 in) 6
Short Pins: 2.79 mm ± 0.25 mm (0.110 in ±0.010 in) 8
Surface mount connections -S
Alternative Voltage Programming equations (1.0V and 1.2V modules only) -V
RoHS Compliant -Z
*Note: Legacy device codes may contain a –B option suffix to indicate 100% factory Hi-Pot tested to the isolation voltage specified
in the Absolute Maximum Ratings table. The 100% Hi-Pot test is now applied to all device codes, with or without the –B option
suffix. Existing comcodes for devices with the –B suffix are still valid; however, no new comcodes for devices containing the –B
suffix will be created.
