Data Sheet
October 5, 2013
EQW012/020/023/025 Series, Eighth-Brick Power Modules:
36 - 75Vdc Input; 1.2Vdc to 5Vdc Output; 12A to 25A Output
LINEAGE POWER 24
Ordering Information
Please contact your Lineage Power Sales Representative for pricing, availability and optional features.
Table 1. Device Codes
Product codes Input Voltage
Output
Voltage
Output
Current
Efficiency
Connector
Type
Comcodes
EQW012A0A1 48V (36-75Vdc) 5.0 V 12 A 91.0 % Through hole 108984444
EQW012A0A61 48V (36-75Vdc) 5.0 V 12 A 91.0 % Through hole 108990280
EQW012A0A81 48V (36-75Vdc) 5.0 V 12 A 91.0 % Through hole 108991650
EQW012A0A1Z 48V (36-75Vdc) 5.0 V 12 A 91.0 % Through hole CC109104972
EQW012A0A6Z 48V (36-75Vdc) 5.0 V 12 A 91.0 % Through hole CC109131570
EQW012A0A1-S 48V (36-75Vdc) 5.0 V 12 A 91.0 % SMT 108980889
EQW012A0A1-SZ 48V (36-75Vdc) 5.0 V 12 A 91.0 % SMT 109100162
EQW020A0F 48V (36-75Vdc) 3.3 V 20 A 88.0 % Through hole 108979428
EQW020A0F1 48V (36-75Vdc) 3.3 V 20 A 88.0 % Through hole 108981952
EQW020A0F1Z 48V (36-75Vdc) 3.3 V 20 A 88.0 % Through hole CC109107050
EQW020A0F61 48V (36-75Vdc) 3.3 V 20 A 88.0 % Through hole 108985698
EQW020A0F61Z 48V (36-75Vdc) 3.3 V 20 A 88.0 % Through hole CC109101796
EQW020A0F61-13 48V (36-75Vdc) 3.3 V 20 A 88.0 % Through hole CC109136710
EQW020A0F8Z 48V (36-75Vdc) 3.3 V 20 A 88.0 % Through hole CC109150455
EQW020A0F1-S 48V (36-75Vdc) 3.3 V 20 A 88.0 % SMT 108980905
EQW020A0F1-SZ 48V (36-75Vdc) 3.3 V 20 A 88.0 % SMT 109100170
EQW023A0G1 48V (36-75Vdc) 2.5V 23 A 87.0 % Through hole 108980624
EQW023A0G1-S 48V (36-75Vdc) 2.5V 23 A 87.0 % SMT 108980921
EQW025A0Y61 48V (36-75Vdc) 1.8 V 25 A 84.0 % Through hole CC109107091
EQW025A0Y61Z 48V (36-75Vdc) 1.8 V 25 A 84.0 % Through hole 108985706
EQW025A0Y1Z 48V (36-75Vdc) 1.8 V 25 A 84.0 % Through hole CC109138913
EQW025A0M61 48V (36-75Vdc) 1.5 V 25 A 81.0 % Through hole 108985714
EQW025A0M1Z 48V (36-75Vdc) 1.5 V 25 A 81.0 % Through hole CC109107067
EQW025A0P1Z 48V (36-75Vdc) 1.2 V 25 A 81.0 % Through hole CC109107083
EQW025A0P1-SZ 48V (36-75Vdc) 1.2 V 25 A 81.0 % SMT 109100187
