Hardware auto-detect and auto-test *******
[DRAM]
DRAM
Test ---------------------------------------------[ PASSED]
[FLASH]
FLASH
Test ---------------------------------------------[ PASSED]
[EEPROM]
EEPROM
Test ---------------------------------------------[ PASSED]
[ETHERNET]
ETHERNET Test ---------------------------------------------[ PASSED]
[UART]
<--Internal Loop Test-->
Port # 1 test in progressing(MODE)------------------------[
RS232]
(Read/WRite)------------------[
SUCCESS]
Port # 2 test in progressing(MODE)------------------------[
RS232]
(Read/WRite)------------------[
SUCCESS]
Port # 3 test in progressing(MODE)------------------------[
RS232]
(Read/WRite)------------------[
SUCCESS]
Port # 4 test in progressing(MODE)------------------------[
RS232]
(Read/WRite)------------------[
SUCCESS]
<--External Uart Test-->
Port # 1 test in progressing(MODE)------------------------[
RS232]
(Read/WRite)------------------[
SUCCESS]
(RTS/CTS)---------------------[
SUCCESS]
(DTR/DSR)---------------------[
SUCCESS]
Port # 2 test in progressing(MODE)------------------------[
RS232]
(Read/WRite)------------------[
SUCCESS]
(RTS/CTS)---------------------[
SUCCESS]
(DTR/DSR)---------------------[
SUCCESS]
Port # 3 test in progressing(MODE)------------------------[
RS232]
(Read/WRite)------------------[
SUCCESS]
(RTS/CTS)---------------------[
SUCCESS]
(DTR/DSR)---------------------[
SUCCESS]
Port # 4 test in progressing(MODE)------------------------[
RS232]
(Read/WRite)------------------[
SUCCESS]
(RTS/CTS)---------------------[
SUCCESS]
(DTR/DSR)---------------------[
SUCCESS]
*******
Hardware auto-detect and auto-test
SUMMARY *******
1. DRAM
Test -----------------------------------------[ PASSED]
2. FLASH
Test -----------------------------------------[ PASSED]
3. EEPROM
Test -----------------------------------------[ PASSED]
4. ETHERNET
Test -----------------------------------------[ PASSED]
5. UART Test Summary
-----------------------------------------------------------------------------
Port Number
|Port Mode | Data Communication Test | RTS/CTS | DTR/DSR |
-----------------------------------------------------------------------------
Port # 1(Internal) | UNKNOWN
|
FAILED
| SKIPPED | SKIPPED |
Port # 1(External) | UNKNOWN
|
FAILED
| FAILED
| FAILED
|
-----------------------------------------------------------------------------
Port # 2(Internal) | UNKNOWN
|
FAILED
| SKIPPED | SKIPPED |
Port # 2(External) | UNKNOWN
|
FAILED
| FAILED
| FAILED
|
-----------------------------------------------------------------------------
Port # 3(Internal) | UNKNOWN
|
FAILED
| SKIPPED | SKIPPED |
Port # 3(External) | UNKNOWN
|
FAILED
| FAILED
| FAILED
|
-----------------------------------------------------------------------------
Port # 4(Internal) | UNKNOWN
|
FAILED
| SKIPPED | SKIPPED |
Port # 4(External) | UNKNOWN
|
FAILED
| FAILED
| FAILED
|
Hardware test is end. Press any key to return the test menu!!
Figure A-9 Hardware test screen within Bios Menu Program
For each hardware component test, the user can skip a test by pressing the
