38
Data ID
ID Description Length
1 Device name var
2 Model name var
3 Serial number var
4 MAC address 6
5 IP address 4
6 Local ports* 1 or 4 or 8
Note :
Local ports: Each 2 byte data represent current local port setting of the corresponding serial port. Local ports data
length of PSx10W should be 2 bytes. Configured local TCP (or UDP) port numbers for each serial port are filled
in the serial port number order base, (i.e. TCP or UDP port number for serial port 1 first). If serial port is disabled,
the local port number of that serial port is regarded as 0.
Example of the PS110W:
If port number = 7001 (1B59h), Local ports data = 1Bh, 59h
If serial port is disabled, Local port data = 00h, 00h
Example of the PS210W:
Port1 = 7001 (1B59h), Port2 = 7010 (1B62h), Port3 = Disable, Port4 = 7004(1B5Ch)
Local ports data = 1Bh, 59h, 1Bh, 62h, 00h, 00h, 1Bh, 5Ch
3.9. NFS server configuration
The Pro Series supports NFS (Network File System) service for system or port data logging functions.
To use this service, the user must specify the IP address of a NFS server and the mounting path on
the NFS server. Figure 3-18 displays the NFS server configuration page located in the web
configuration interface.
Figure 3-98 NFS server configuration
To store the Pro Series log data to the NFS server, the NFS server must be configured as “read and
write allowed”. If there is a firewall between the Pro Series and the NFS server, there must be a rule
that allows all outgoing and incoming packets to travel across the firewall.
If the NFS service is enabled and the NFS server configuration is properly set up, the user may
