36
Table 3-2 Input examples of Option and IP address/mask combination
Input format
Allowable Hosts
IP address/mask
Option
Any host 0.0.0.0/0.0.0.0 Normal
192.168.1.120 192.168.1.120/255.255.255.255 Normal
Any host except
192.168.1.120
192.168.1.120/255.255.255.255 Invert
192.168.1.1 ~
192.168.1.254
192.168.1.0/255.255.255.0 Normal
192.168.0.1 ~
192.168.255.254
192.168.0.0/255.255.0.0 Normal
192.168.1.1 ~
192.168.1.126
192.168.1.0/255.255.255.128 Normal
192.168.1.129 ~
192.168.1.254
192.168.1.128/255.255.255.128 Normal
None 0.0.0.0/0.0.0.0 Invert
3.7. SYSLOG server configuration
The Pro Series supports the use of a remote message logging service, SYSLOG service for the
system and port data logging. To use the remote SYSLOG service, the user must specify the
SYSLOG server’s IP address and the facility to be used. Figure 3-16 shows the SYSLOG server
configuration page which is located in the Web interface.
Figure 3-76 SYSLOG server configuration
To receive log messages from the Pro Series, the SYSLOG server must be configured as “remote
reception allowed”. If there is a firewall between the Pro Series and the SYSLOG server, there must
be a rule that allows all outgoing and incoming UDP packets to travel across the firewall.
The Pro Series supports SYSLOG facilities from local0 to local7. The user can employ these
facilities to save messages from the Pro Series separately in the SYSLOG server.
If the SYSLOG service is enabled and the SYSLOG server configuration is properly set up, the user
may configure the storage location for the system log or port data log of the Pro Series as SYSLOG
server. For more information about the configuration of port/system log storage location, please refer
to section, 4.2.8 Port Logging and 5.2 System Logging.
