Parts list – Buyers 13006039 User Manual
Page 7
7
ITEM
PART NO.
QTY. DESCRIPTION
1
3019421
SALEABLE
1
LIFTGATE, FIRST SUB ASSY, 60IN
2
3016802
1
FRAME, UPPER
3
3016804
1
TUBE, MAIN ACTUATING
4
3016803
2
ARM, PIVOT DS & PS
5
3016816
2
CONNECTOR, CYLINDER MECHANICAL
6
3015442
2
CYLINDER, LIFTDOGG, 3/4 ROD
7
3015441
2
SPACER, WASHER
8
3015440
2
PIVOT, ADAPTER ARM EXTENSION inner
9
3018370
2
PIVOT, ADAPTER ARM EXTENSION
10
3016858
2
RING, .875 RETAINING
11
3016859
10
RING, .75" RETAINING
12
3016809
2
PIN, ANTI-ROTATION W/ LONG GREASE PIN
13
3016810
2
PIN, ANTI-ROTATION W/ LONG PIN
14
3016057
2
COVER, TOP UPRIGHT FRAME
15
3016058
2
RETAINER, UPRIGHT FRAME &
PLATFORM
16
3016860
2
SCREW,SOCKET, 1/4-20X.5 SST
17
3015595NR
1
POWER UNIT, HYDRAULICS
18
H5715X4X4X6
1
TEE,STRAIGHT THRD BRANCH
1/4 JUMP
19
3016328
1
WIRE ASSEMBLY, LIFTGATE 23ft
20
3016646
1
ANGLE, LONG MOUNTING
21
3016647
2
PLATE, MOUNTING BOTTOM
22
3016863
1
CAB CONNECTORS, MULTICONDUCTOR
CONDUIT
23
3018893
28
SCREW, SELF DRILL-SST, 10-16
24
3016867
2
SCREW, SELF TAP, 8-18X.38, SST
25
66003
1
PIN, 3/16 LYNCH
26
FCS038016100SS
3
SCREW, HHC 3/8-16 X 1 304 SST
27
FNE038016044SS
1
NUT, NYLOCK 3/8-16 X 7/16 SST
28
FCS050013100SS
3
SCREW, HHC-1/2-13 X 1 SST
29
3006202
4
SCREW, HEX HD - 1/2-13 X 1-1/2
GR 8 ZC
30
3016864
5
NUT, 1/2-13 FLANGE, NYLOCK, ZN
31
FNE050013053
2
NUT, NYLOCK 1/2-13 ZINC
32
FWF063131095
1
WASHER, 5/8 SAE FLAT ZN
33
3003873
5
WASHER, FLAT 1/2 ID SST
34
CDC01Z
1
DUST COVER, LOCK CYLINDER
35
3016856
2
CABLE, STEEL W/ 3/16 RING LYNCH
36
3016865
12
WASHER, #10, SST
37
3017150
1
SWITCH, KEY AND HARNESS
38
3016861
3
SPRING, COMP, 1/2 ID X 1.00 LONG
39
FCS050013150SS
2
SCREW, HHC-1/2-13 X 1.50 SST
40
3016988
1
LEVER, LOCK
41
3002215
1
BOLT, CARRIAGE 1/2-13 X 1.75 GR5 ZN
42
3016061
1
HOSE, 1/4 X 29 INCH
Parts List
ITEM
PART NO.
QTY. DESCRIPTION
43
3016062
1
HOSE, 1/4 X 56 INCH
44
3019457
1
CAP PLUG, 15/16 -PIP-IB-17
45
3017149
1
WIRE HARNESS ASSEMBLY
46
FNE025020031
2
NUT, NYLON INSERT 1/4-20 ZINC
47
3017164
3
NUT, CLIP ON, 5/16-18 .025-.150
48
H5315X4
2
ADAPTOR, -4M SAE ORB TO -4M JIC
49
FCS031018063SS
1
SCREW, HHC 5/16-18 X 5/8 SST
50
92401213
2
NUT, HEX REV-1/2-13 GR A ZN
51
3001376
2
SCREW, 3/8 X 1 1/2 HEX LAG
52
3018393
2
CUSHION, RUBBER 2.5 IN LONG ARC
53
3016806
1
FRAME, MID MOBILE
54
3016808
4
PIN, ANTI-ROTATION W/ SHORT PIN
55
3016862
2
RETAINER, RING 1/2
56
FWL050088013SS
1
WASHER, LOCK - 1/2 SPLIT SST
57
3015598
2
COVER, BELTED RUBBER
58
FWL038069009SS
2
WASHER, LOCK RHS-3/8 SST
59
3016817
1
KIT, LIFTDOGG MISC PARTS
60
3016805
1
BOX, LINCENSE PLATE COVER
61
FCS031018063SS
3
SCREW, HHC 5/16-18 X 5/8 SST
62
FWF031075006SS
3
WASHER, 5/16 SAE SST
63
3018390
2
CAP PLUG, 2 INCH
64
3016657
7
CAP PLUG, 1.25 INCH
65
3017181
2
DECAL, STAY AWAY
66
3017178
1
DECAL, WARN- DON'T EXCEED
67
3017177
1
DECAL, WARNING
68
3016843
1
DECAL, LiftDogg LOGO
69
3017180
2
DECAL, CAUTION LABEL
70
3016801
1
PLATFORM, MAIN
71
3015455
1
COLLAR, SLEEVE
72
3016811
1
HANDLE, TORSION SPRING HOLDING DS
73
3016812
1
HANDLE, TORSION SPRING HOLDING PS
74
3015589
1
SPRING, TORSION BAR
75
3016814
2
LINKAGE, WELDMENT DS+PS
76
FNE050013053
1
NUT, NYLOCK 1/2-13 ZINC
77
FCS050013150SS
1
SCREW, HHC-1/2-13 X 1.50 SST
78
3016857
2
ANTISKID TAPE, 4X16, SELF ADHESIVE
79
3016807
1
PLATFORM, RAMP
80
3016056
2
PIN, 1/2" X LENGTH ZINC PLATED
81
FPC013000100
2
COTTER PIN, 1/8 X 1, ZINC
82
3003873
4
WASHER, FLAT 1/2 ID SST
83
3016850
1
COVER, GAP DIAMOND TREAD
84
750
1
CLAMP, HOSE .750, 13/32 HOLE
85
FCS038016075SS
1
SCREW, HHC-3/8-16 X 3/4 SST
86
FNE038016044SS
1
NUT, NYLOCK 3/8-16 X 7/16 SST
87
3019442
1
LABEL, SERIAL NUMBER
88
3018392
1
DECAL, NESTED LOGO & MISC
