Page 4: Testing and maintenance
15461 Slover Ave., Fontana, CA 92337 - Phone: (909) 947-0015 - Fax: (909) 947-0603 -
Installation Instructions (continued)
30.
After all the hose clamps are tightened
remember to reconnect the three latches on
the side of the intake box.
SEE EXPLODED VIEW ON PAGE 6
4
P/N: 75-5067 / 75-5067D
29.
Attach the top turbo inlet tube completely
and again tighten the hose clamp.
28.
Attach the bottom tube to the bottom
turbo inlet and push in completely. After the
tube is pushed in all the way tighten the hose
clamp.
32.
Note
: if your vehicle has a hose that
connects from the intake tube to the crank
case remember to connect the hose firmly to
the S&B hose fitting
(D)
.
33.
Fasten the air box lid
(P)
using the
provided hardware
(E & F)
.
35.
The install of the S&B Intake kit is now
complete.
Related Items to Your
Purchase
• Replacement Air Filter (Oiled)
(S&B P/N: KF-1058)
• Replacement Air Filter (Dry)
(S&B P/N: KF-1058D)
• Air Filter Wrap (S&B P/N: WF-1058)
Precision II
Filter Cleaning & Oiling
through your local S&B distributor.
Part #: 88-0008
31.
Plug the harness into the sensor under
the intake tube. Press in firmly till it locks.
Note
: older vehicles must also press in the
Red
lock tab after the harness is connected.
34.
Reconnect the battery. Inspect your
installation, make sure the kit is properly
positioned and all fasteners are secure.
Testing and Maintenance
• Engage parking brake and start your engine. Listen for abnormal noises. If an air leak
is detected, re-inspect hoses and connections as they may need to be repositioned
and tightened.
• S&B FILTERS recommends that you keep your OE intake system in the event it is
required in the future.
• In order to maintain your warranty, all connections and components must be checked
periodically for alignment and for proper tension on all connections. Failure to do so
may void your warranty.
• Use only S&B FILTERS cleaning and oil products to service your filter. Using any other
brand oil and or cleaners on your S&B air filter may void your warranty. See
for complete warranty information.
