Page 4
J1 mates with Molex housing 43061-0003
and Molex series 5194 crimp terminals.
Optional ground (0.25 faston) tab available.
J2 mates with Molex housing 43061-0012 and
Molex series 5194 crimp terminals.
www.powersolve.co.uk
Powersolve Electronics Ltd. 8A, Arnhem Road, Newbury, RG14 5RU. England
Tel:01635 521858 Fax: 01635 523771 Email: [email protected]
AC-DC Converters
MODELS AND RATINGS
Single Output Models
DERATING CURVES
Notes:
1. All dimensions in inches (mm). Tolerance .xx = ±0.02 (0.50); .xxx = ±0.01 (0.25)
2. Cover dimensions are 4.96 x 3.05 x 1.52 (126 x 77.5 x 38.5)
4X ø0.156 [3.96] mounting holes
ø0.312 [7.92] clearance top and bottom
SMD component height
1.20 (30.5)
0.14 [3.5]
4.50 (114.3)
2.50
(63.5)
2.25
(57.15)
4.25 (107.95)
J2
J1
1
12
1
2
V Adj.
Weight: approx.
0.4 lb (180g)
20
10
30
40
50
60
70
80
0
60
100
)
W(
re
wo
Pt
upt
u
O
Ambient Temp (°C)
0
80
20
40
A
D
C
A
B
C
D
B
24-48V
12-18V
5V
3.3V
20
10
30
40
50
60
70
80
0%
50%
100%
re
wo
Pt
upt
u
O
Ambient Temp (°C)
0
75%
25%
Note:
1. Derate by 10% if cover is fitted.
2. For multi output convection-
cooled operation above +50 ºC
derate linearly to 50% at +70 ºC.
All MHP100 models with 5 CFM
All MHP100 single output models convection-cooled
MODEL
OUTPUT
OUTPUT CURRENT
NUMBER
VOLTAGE
MINIMUM
MAXIMUM
WITH 5 CFM COOLING
MHP100-3V3(C)
+3.3 V
0.0 A
15.0 A
20.0 A
MHP100-05(C)
+5.0 V
0.0 A
15.0 A
20.0 A
MHP100-07(C)
+7.0 V
0.0 A
11.4 A
14.3 A
MHP100-09(C)
+9.0 V
0.0 A
8.8 A
11.1 A
MHP100-12(C)
+12.0 V
0.0 A
7.5 A
8.3 A
MHP100-15(C)
+15.0 V
0.0 A
6.0 A
6.6 A
MHP100-18(C)
+18.0 V
0.0 A
5.0 A
5.5 A
MHP100-24(C)
+24.0 V
0.0 A
4.1 A
4.1 A
MHP100-33(C)
+33.0 V
0.0 A
3.0 A
3.0 A
MHP100-48(C)
+48.0 V
0.0 A
2.1 A
2.1 A
Multi Output Models
4X ø0.156 [3.96] mounting holes
ø0.312 [7.92] clearance top and bottom
SMD component height
1.20 (30.5)
0.14 [3.5]
4.50 (114.3)
2.50
(63.5)
2.25
(57.15)
4.25 (107.95)
J2
J1
1
12
1
2
V Adj.
Weight: approx.
0.4 lb (180g)
20
10
30
40
50
60
70
80
0
60
100
)
W(
re
wo
Pt
upt
u
O
Ambient Temp (°C)
0
80
20
40
A
D
C
A
B
C
D
B
24-48V
12-18V
5V
3.3V
20
10
30
40
50
60
70
80
0%
50%
100%
re
wo
Pt
upt
u
O
Ambient Temp (°C)
0
75%
25%
Note:
1. Derate by 10% if cover is fitted.
2. For multi output convection-
cooled operation above +50 ºC
derate linearly to 50% at +70 ºC.
All MHP100 models with 5 CFM
All MHP100 single output models convection-cooled
OUTPUT POWER
OUTPUT 1
OUTPUT 2
OUTPUT 3
OUTPUT 4
MODEL
CONVECTION FORCED AIR VOLTAGE
CURRENT
VOLTAGE
CURRENT
VOLTAGE
CURRENT
VOLTAGE
CURRENT
NUMBER
COOLED 5CFM
MIN/MAX
MIN/MAX
MIN/MAX
MIN/MAX
MHP100-512(C)
80 W
100 W
+5.0 V
0.0 A/12.0 A
+12.0 V
0.0 A/3.0 A
MHP100-515(C)
80 W
100 W
+5.0 V
0.0 A/12.0 A
+15.0 V
0.0 A/3.0 A
MHP100-51212(C)
75 W
100 W
+5.0 V
0.5 A/10.0 A
+12.0 V
0.0 A/3.0 A
-12.0 V
0.0 A/0.8 A
MHP100-52412(C)
80 W
100 W
+5.0 V
0.5 A/10.0 A
+24.0 V
0.0 A/2.0 A
-12.0 V
0.0 A/0.8 A
MHP100-51515(C)
80 W
100 W
+5.0 V
0.5 A/10.0 A
+15.0 V
0.0 A/3.0 A
-15.0 V
0.0 A/0.8 A
MHP100-33512(C)
65 W
100 W
+3.3 V
0.5 A/10.0 A
+5.0 V
0.0 A/5.0 A
+12.0 V
0.0 A/0.8 A
MHP100-53312(C)
70 W
100 W
+5.0 V
0.5 A/10.0 A
+3.3 V
0.0 A/5.0 A
+12.0 V
0.0 A/0.8 A
MHP100-5125(C)
80 W
100 W
+5.0 V
0.5 A/10.0 A
+12.0 V
0.0 A/3.0 A
-5.0 V
0.0 A/0.8 A
MHP100-5155(C)
70 W
100 W
+5.0 V
0.5 A/10.0 A
+15.0 V
0.0 A/3.0 A
-5.0 V
0.0 A/0.8 A
MHP100-53312D(C)
65 W
100 W
+5.0 V
0.5 A/10.0 A
+3.3 V
0.1 A/5.0 A
+12.0 V
0.0 A/0.8 A
-12.0 V
0.0 A/0.5 A
MHP100-33512D(C)
60 W
100 W
+3.3 V
0.5 A/10.0 A
+5.0 V
0.1 A/5.0 A
+12.0 V
0.0 A/0.8 A
-12.0 V
0.0 A/0.5 A
MHP100-52412D(C)
80 W
100 W
+5.0 V
0.5 A/10.0 A
+24.0 V
0.1 A/2.0 A
+12.0 V
0.0 A/0.8 A
-12.0 V
0.0 A/0.5 A
MHP100-52415D(C)
80 W
100 W
+5.0 V
0.5 A/10.0 A
+24.0 V
0.1 A/2.0 A
+15.0 V
0.0 A/0.8 A
-15.0 V
0.0 A/0.5 A
MHP100-512D5(C)
80 W
100 W
+5.0 V
0.5 A/10.0 A
+12.0 V
0.1 A/3.0 A
-12.0 V
0.0 A/0.8 A
-5.0 V
0.0 A/0.5 A
MHP100-515D5(C)
80 W
100 W
+5.0 V
0.5 A/10.0 A
+15.0 V
0.1 A/3.0 A
-15.0 V
0.0 A/0.8 A
-5.0 V
0.0 A/0.5 A
Notes:
1. To receive unit with cover fitted, add suffix (-C) to model number.
2. Output 3 available with opposite polarity for OEM quantities.
3. MHP100 models are class I only, contact sales for class II.
MECHANICAL DETAILS
Pin 1
Line
Pin 2
Neutral
Input Connector J1
Pin
Single Multi
1
+V1
+V1
2 +V1
+V1
3
+V1 +V1
4
+V1
+V1
5 V1
RTN
RTN
6
V1 RTN
RTN
7
V1 RTN
RTN
8 V1
RTN
RTN
9 NOT USED
+V2
10
NOT USED
+V2
11 NOT USED ±V3
12 NOT USED -V4
Output Connector J1
