J1 mates with
Molex housing 43061-0003 &
Molex series 5194 crimp terminals.
Optional ground (0.25 faston) tab
available, contact sales.
J2 mates with
Molex housing 43061-0006 &
Molex series 5194 crimp terminals.
Weight: approx. 0.33 lb (150 g)
Notes:
1. V2 will track a change in V1 by the same percentage change in voltage as V1 is trimmed.
2. To receive unit with cover fitted, add suffix (-C) to model number. For Class I operation only.
3. A 120% peak load can be taken for up to 100 ms with a 25% duty cycle. Average load not to exceed 60 W.
www.powersolve.co.uk
Powersolve Electronics Ltd. 8A, Arnhem Road, Newbury, RG14 5RU. England
Tel:01635 521858 Fax: 01635 523771 Email: [email protected]
AC-DC Converters
MODELS AND RATINGS
MECHANICAL DETAILS
DERATING CURVES
Notes:
1. All dimensions in inches (mm). Tolerance .xx = ±0.02 (0.50); .xxx = ±0.01 (0.25)
2. Cover dimensions are 4.49 x 2.52 x 1.52 (114 x 64 x 38.5)
20 10 30 40 50 60 70 80
0 %
75%
r
e
w
o
P
t
u
pt
u
O
Ambient T (°C)
0
100%
25%
50%
20 10 30 40 50 60 70 80
0 %
50%
100%
r
e
w
o
P
t
u
pt
u
O
Ambient T (°C)
0
75%
25%
4X ø0.156 (3.96) mounting holes
ø0.312 (7.92) clearance top and bottom
SMD component height
V Adj.
1.20
(30.5)
0.14 (3.5)
4.00 (101.6)
2.00
(50.8)
1.75
(44.45)
3.75 (95.25)
6
1
2
1 J2
J1
All MHP60 models convection-cooled All MHP60 models with 5 CFM
20 10 30 40 50 60 70 80
0 %
75%
r
e
w
o
P
t
u
pt
u
O
Ambient Temp (°C)
0
100%
25%
50%
20 10 30 40 50 60 70 80
0 %
50%
100%
r
e
w
o
P
t
u
pt
u
O
Ambient Temp (°C)
0
75%
25%
Note: Derate by 10% if cover is fitted
4X ø0.156 (3.96) mounting holes
ø0.312 (7.92) clearance top and bottom
SMD component height
V Adj.
1.20
(30.5)
0.14 (3.5)
4.00 (101.6)
2.00
(50.8)
1.75
(44.45)
3.75 (95.25)
6
1
2
1 J2
J1
All MHP60 models convection-cooled All MHP60 models with 5 CFM
OUTPUT 1 OUTPUT 2 OUTPUT 3
MODEL VOLTAGE CURRENT VOLTAGE CURRENT VOLTAGE CURRENT OUTPUT
NUMBER MIN/MAX MIN/MAX MIN/MAX POWER
MHP60-05(C) +5.0 V 0.0 A/12.00 A 60W
MHP60-07(C) +7.0 V 0.0 A/8.60 A 60W
MHP60-09(C) +9.0 V 0.0 A/6.70 A 60W
MHP60-12(C) +12.0 V 0.0 A/5.00 A 60W
MHP60-15(C) +15.0 V 0.0 A/4.00 A 60W
MHP60-18(C) +18.0 V 0.0 A/3.30 A 60W
MHP60-20(C) +20.0 V 0.0 A/3.00 A 60W
MHP60-24(C +24.0 V 0.0 A/2.50 A 60W
MHP60-33(C) +33.0 V 0.0 A/1.80 A 60W
MHP60-48(C) +48.0 V 0.0 A/1.25 A 60W
MHP60-512(C) +5.0 V 0.5 A/8.00 A +12.0 V 0.1 A/3.0 A 60W
MHP60-515(C) +5.0 V 0.5 A/8.00 A +15.0 V 0.1 A/2.5 A 60W
MHP60-51212(C) +5.0 V 0.5 A/8.00 A +12.0 V 0.1 A/3.0 A -12.0 V 0.0 A/0.5 A 60W
MHP60-52412(C) +5.0 V 0.5 A/8.00 A +24.0 V 0.1 A/1.5 A -12.0 V 0.0 A/0.5 A 60W
MHP60-51515(C) +5.0 V 0.5 A/8.00 A +15.0 V 0.1 A/2.5 A -15.0 V 0.0 A/0.5 A 60W
MHP60-33512(C) +3.3 V 0.5 A/8.00 A +5.0 V 0.1 A/1.5 A +12.0 V 0.0 A/0.5 A 60W
MHP60-53312(C) +5.0 V 0.5 A/8.00 A +3.3 V 0.1 A/1.5 A +12.0 V 0.0 A/0.5 A 60W
Pin 1 Line
Pin 2 Neutral
Input Connector J1
Pin Single Multi
1 +V1 +V1
2 +V1 +V1
3 RTN RTN
4 RTN RTN
5 NC -V3
6 NC
+V2
Output Connector J1
(3)
