ES150
Page 1 - 4 SPECIFICATIONS Rev. Sept. 2012
Hold-Up time (230 VAC in put)
Vout = 100% , Iout = 100%
Vout = 85% , Iout = 100%
Vout = 100% , Iout = 50% 25 ms
40 ms
60 ms
Turn on de lay (230 VAC in put)
af ter mains switch on 250 ms
In rush cur rent 10 A with NTC re sis tor 30 Ohms cold re sis tance
ES 015-10 ES 030-5 ES 075-2 ES 0300-0.45
Se ries op er a tion
max. to tal volt age
Mas ter / Slave op er a tion 600 V
with op tional ex ter nal Mas ter / Slave Adapter
Par al lel op er a tion
max. to tal cur rent
Mas ter / Slave op er a tion no limit
max. 4 units
Re mote sens ing (op tional) op tion P119 op tion P120 op tion P121 op tion P122
max. volt age drop per load lead 2 V
Note: volt age drop across load leads will sub tract from max. avail able out put volt age
Over Volt age Limit (fixed) max. 18 V max. 40 V max. 90 V max. 330 V
Po ten ti om eters
front panel con trol with knobs
res o lu tion
screw driver ad just ment
at front panel
stan dard
0.03%
op tion P001
Me ters
scale volt age
scale cur rent
ac cu racy V-me ter
ac cu racy A-me ter
3.5 digit
0 - 15.00 V
0 - 10.00 A
0.5% + 2 dig its
1% + 2 dig its
3.5 digit
0 - 30.0 V
0 - 5.00 A
0.5% + 2 dig its
1% + 2 dig its
3.5 digit
0 - 75.0 V
0 - 2.00 A
0.5% + 2 dig its
1% + 2 dig its
3.5 digit
0 -300 V
0 - 450 mA
0.5% + 2 dig its
1% + 2 dig its
In put Con nec tor Euro-con nec tor at rear panel 10 Amp / 65 °C IEC320/C14, EN60320/C14
Out put Ter mi nals Stan dard: 4 mm safety sock ets at front-panel
Op tion: screw ter mi nals (0.2-4 mm
2
) at rear-panel (sock ets at front re moved)
only com bined with re mote sens ing, see re mote sens ing for op tion
num bers (P119 - 122)
Pro gram ming con nec tor 15 pole D-con nec tor at rear panel (FE MALE)
Cool ing Con vec tion cool ing
En clo sure de gree of pro tec tion IP20
Di men sions (h x w x d) 52 x 222 x 202 mm
Weight 1.7 kg
Connections pro gram ming con nec tor Di men sions
CV = Con stant Volt age
CC = Con stant Cur rent
OVL = Over Volt age Limit
Spec i fi ca tions mea sured at t
amb
= 25 ± 5 °C and
Vin = 230 VAC, 50 Hz un less oth er wise noted.
