Wall Mounting Plate
Option ‘W’ available for 3U/6U models.
Higher input current models use stud terminals.
Ordering Details
Example: CI1628.5 describes an inverter operating from a battery voltage
in the range 18-36 VDC and provides a 50 Hz sinusoidal output of
230 V RMS at 500 VA.
Other Options
See AC-DC C Series for options.
Customised designs - to special order - consult Sales.
Frequency Designation
Add suffix to model number
.0 External control (specify at time of order)
.1 45-400 Hz adjustable
.2 45-65 Hz Adjustable
.4 400 Hz
.5 50 Hz
.51 Synchronized with 50 Hz mains
.6 60 Hz
.61 Synchronised with 60 Hz mains
.7 50/60 Hz switchable
.1 and .2 Frequency internally or externally adjustable/programmable
.4, 5 and .7 Frequency fixed, crystal stabilised
NOTE:
.0 not for IT or IV series.
Application Details
SS Series - Static Switch Specification 0.8-10 kVA
Input
Input Voltage • 115 VAC or 230 VAC models - See Table
Input Frequency • 50 Hz, 60 Hz and 400 Hz models
See Application Details
Output
Output Power • 800 VA to 10 kVA - See Tables
Switching Times • Mains to inverter (mains priority) ≤1/2
period, typ 1/4 period (incl. failure
detection time) or inverter to mains
(inverter priority) 1 period, typ 1/2 period
with a current >15 A
Return to mains (mains priority) or return
to inverter (inverter priority) practically
no interruption
Switching Point • 0.8 Vnom
Surge Current • 5 x Inom for 1 sec
Output Protection • Short circuit protected for output
current ≤15 A, external fuse for
output current >15 A
Temperature Coefficient • 0.05%/ºC
General
Signal Inputs • Logic low = 0 to 5 V,
logic high = 12 to 30 V via opto coupler
Relay Contacts • V max = 250 VAC, I max = 3 A
Connectors • One H15 and one F48 or terminal block
with wall mount option
Environmental
Operating Temperature • -20 ºC to +75 ºC, derate from +55 ºC at
2.5%/ºC (optional -40 °C to +75 °C)
Storage Temperature • -40 ºC to +85 ºC
EMC & Safety
Isolation Resistance • >10 MΩ at 500 VDC
Isolation Test • EN60950, Class 1
Creepage Distance • VDE 0110 ≥4 mm
Safety Approvals • EN60950, Class 1
Application Details
Example:
SS1508.5 is a Static Switch for 230 VAC operation
at 50 Hz and is capable of handling 1.6 kVA. Frequency Designation
Model Number
Designator Frequency
SSXXXX .4 400 Hz
.5 50 Hz
.6 60 Hz
SS Series - Output Ratings & Mechanical Dimensions
Input/Output Output Dimensions Model
Voltage AC Power Height Width Depth (mm) Number
1.6 kVA 6U 21TE 166.5 SS1508
1.6 kVA 6U 21TE 226.0 SS3508
230 V AC 3.2 kVA 6U 21TE 226.0 SS3518
4.6 kVA 6U 21TE 226.0 SS3528
10.0 kVA 6U 21TE 226.0 SS3538
0.8 kVA 6U 21TE 166.5 SS1506
1.6 kVA 6U 21TE 166.5 SS1516
115 V AC
1.6 kVA 6U 21TE 226.0 SS3506
3.0 kVA 6U 21TE 226.0 SS3516
5.0 kVA 6U 21TE 226.0 SS3526
10.0 kVA 6U 21TE 226.0 SS3536
UPS/INVERTERS
