CI Series - Converters & Inverters, Isolated DC Input 0.5-3.5 kVA
F
Notes:
1. Models supplied by external PFC module with 93-264 VAC input.
2. For 12 V DC nominal input contact sales. 3. External fan recommended, details to be advised at time of order.
INPUT VOLTAGE DC
20-32 V Output 40-64 V 50-80 V Output 80-160 V Output 160-320 V 170-200 V 320-650 V Output 380-400 V Output
Models Rating Models Models Rating Models Rating Models Models (1) Models Rating Models (2) Rating
I1520 0.20 kVA I1530 I1540 0.45 kVA I1550 0.50 kVA I1570 I1506 - 0.80 kVA I1508 1.0 kVA
- - I3530 I3540 0.50 kVA I3550 0.80 kVA I1370 I1306 I3570G 1.20 kVA I3508 1.5 kVA
I3720 0.40 kVA I3730 I3740 0.60 kVA I3750 1.20 kVA I3770 I3706 I3770G 2.00 kVA I3708 2.5 kVA
- - I4730 I4740 1.20 kVA I4750 2.00 kVA I4770 I4706 I4770G 3.00 kVA I4708 4.0 kVA
I5620 1.20 kVA - I5640 2.00 kVA I5650 3.00 kVA I5670 I5606 I5670G 5.00 kVA I5608 6.0 kVA
I5720 1.60 kVA I5730 I5740 3.00 kVA I5750 5.00 kVA I5770 I5706 I5770G 8.00 kVA I5708 10.0 kVA
- - - - - - - I5870 I5806 I5870G 10.0 kVA I5808 12.0 kVA
12 V - 24 V 30 V - 50 V - 100 V 115 V 200 V - 230 V -
OUTPUT VOLTAGE AC (3)
Notes:
1. Designed for 115 VAC output.
2. Designed for 230 VAC output with pre-connected converter series C,
or for PFC modules series P (no isolation between input & output).
3. Maximum AC output at minimum DC input voltage. Higher output voltage is
available at higher input voltage. Maximum AC output (Vrms) ≤0.65 input VDC.
Input (VDC) 20-32 V Output 40-64 V 50-80 V 80-160 V 160-320 V 320-380 V 320-640 V Output
Output Models Rating Models Models Models Models Models
(1)
Models Rating
115 V (110-125 V) CI1626 0.5 kVA CI1636 CI1646 CI1656 CI1676 CI1686Z - 0.6 kVA
230 V (210-245 V) CI1628 0.5 kVA CI1638 CI1648 CI1658 CI1678 CI1688Z - 0.6 kVA
115 V (110-125 V) CI3626 1.0 kVA CI3636 CI3646 CI3656 CI3676 CI3686Z CI3676G 1.2 kVA
230 V (210-245 V) CI3628 1.0 kVA CI3638 CI3648 CI3658 CI3678 CI3688Z CI3678G 1.2 kVA
115 V (110-125 V) CI4826 (3) 1.4 kVA CI4836 (3) CI4846 (3) CI4856 (3) CI4876 (3) CI4886Z (3) CI4876G (3) 1.8 kVA
230 V (210-245 V) CI4828 (3) 1.4 kVA CI4838 (3) CI4848 (3) CI4858 (3) CI4878 (3) CI4888Z (3) CI4878G (3) 1.8 kVA
115 V (110-125 V) CI5626 1.8 kVA CI5636 CI5646 CI5656 CI5676 CI5686Z CI5676G 1.8 kVA
230 V (210-245 V) CI5628 2.0 kVA CI5638 CI5648 CI5658 CI5678 CI5688Z CI5678G 2.0 kVA
115 V (110-125 V) CI5726 2.5 kVA CI5736 CI5746 CI5756 CI5776 CI5786Z CI5776G 2.5 kVA
230 V (210-245 V) CI5728 2.5 kVA CI5738 CI5748 CI5758 CI5778 CI5788Z CI5778G 2.5 kVA
115 V (110-125 V) CI5726F (3) 3.0 kVA CI573t6F (3) CI5746F (3) CI5756F (3) CI5776F (3) CI5786ZF (3) CI5776GF (3) 3.5 kVA
230 V (210-245 V) CI5728F (3) 3.0 kVA CI5738F (3) CI5748F (3) CI5758F (3) CI5778F (3) CI5788ZF (3) CI5778GF (3) 3.5 kVA
Input (VDC) 20-32 V Output 40-64 V 50-80 V Output 80-160 V Output 160-320 V 340-400 V 360-650 V Output
Output Models Rating Models Models Rating Models Rating Models Models (1) Models Rating
115 V (110-125 V) IT1626 0.2 kVA IT1636 IT1646 0.4 kVA IT1656 0.5 kVA IT1676 IT1686Z - 0.5 kVA
230 V (210-245 V) IT1628 0.2 kVA IT1638 IT1648 0.4 kVA IT1658 0.5 kVA IT1678 IT1688Z - 0.5 kVA
115 V (110-125 V) - - IT3636 IT3646 0.5 kVA IT3656 1.0 kVA IT3676 IT3686Z IT3676G 1.0 kVA
230 V (210-245 V) - - IT3638 IT3648 0.5 kVA IT3658 1.0 kVA IT3678 IT3688Z IT3678G 1.0 kVA
115 V (110-125 V) IT3826 0.4 kVA IT3836 IT3846 0.6 kVA IT3856 1.2 kVA IT3876 IT3886Z IT3876G 1.6 kVA
230 V (210-245 V) IT3828 0.4 kVA IT3838 IT3848 0.6 kVA IT3858 1.2 kVA IT3878 IT3888Z IT3878G 1.6 kVA
115 V (110-125 V) - - - - 1.2 kVA IT4856 2.0 kVA IT4876 IT4886Z IT4876G 2.5 kVA
230 V (210-245 V) - - - - 1.2 kVA IT4858 2.0 kVA IT4878 IT4888Z IT4878G 2.5 kVA
115 V (110-125 V) - - IT5636 IT5646 2.0 kVA IT5656 3.0 kVA IT5676
(2)
IT5686Z
(2)
IT5676G
(2)
5.0 kVA
230 V (210-245 V) - - IT5638 IT5648 2.0 kVA IT5658 3.0 kVA IT5678
(2)
IT5688Z
(2)
IT5678G
(2)
5.0 kVA
115 V (110-125 V) - - IT5736 IT5746 3.0 kVA IT5756
(2)
5.0 kVA IT5776
(2)
IT5786Z
(2)
IT5776G
(2)
8.0 kVA
230 V (210-245 V) - - IT5738 IT5748 3.0 kVA IT5758
(2)
5.0 kVA IT5778
(2)
IT5788Z
(2)
IT5778G
(2)
8.0 kVA
115 V (110-125 V) - - - - - - - IT5876
(2)
IT5876Z
(2)
IT5876G
(2)
10.0 kVA
230 V (210-245 V) - - - - - - - IT5878Z
(2)
IT5878Z
(2)
IT5878G
(2)
10.0 kVA
Notes:
1. Models supplied by by external PFC module with 93-264 V AC input.
2. Output transformer needs to be installed externally because of weight
e.g. on mounting plate (wall mount version).
3. For other output voltages the output transformer can be modified - contact Sales.
I Series - Inverters, Non-Isolated 0.2-12.0 kVA
IT Series - Inverters & Transformers, Isolated 1 Phase 0.2-10.0 kVA
