P1.1.4 Minimum Freq 0.00 Max freq Hz The set minimum operating frequency.
P1.1.5 Maximum Freq Min freq 120.00 Hz The maximum frequency may not be higher than the motor nominal frequency for listed
motors.
P1.1.6 Reverse Plugging 50 100 % See Chapter "Reverse plugging"
P1.1.7 Stop Function 0 1 Stopping mode selection
0 = Brake
1 = Ramping, default
Ramping: When the drive command is switched off the motion is stopped according to
the set deceleration ramp.
Brake: When the drive command is switched off the motor current is cut off, then the
motion is stopped by the mechanical brake.
P1.1.8 MSFreq2/Slowdown 0 100 Hz Slowdown frequency and Multistep frequency2
P1.1.9 Multistep Freq 3 0 100 Hz 3 rd preset speed.
P1.1.10 Multistep Freq 4 0 100 Hz 4 th preset speed.
P1.1.11 Input set 0 7 Control mode selection, see Chapter "control methods"
0 = MS2 (stop-limit)
1 = MS2/MS3 (slow-limit)
2 = EP2 (stop-limit)
3 = EP2 (slow-limit)
4 = EP3
5 = MS4
6 = MS5
7 = AU (Ain)
G1.2 Motor Parameters
Code Name Min Max Unit Description
P1.2.1 Motor Nominal
Voltage 200 500 V Nominal motor voltage Un from motor nameplate.
P1.2.2 Motor Selection 0 9 0 = Not Used
1 = Free Travel
2 = MF06MA100
3 = MF06MA200
4 = MF06LA100
5 = MF06LA200 (MF06LA200, 0.45kW/400V; 0.55kW/460V)
6 = MF06LA20P (MF06LA200, 0.65kW/400V; 0.75kW/460V)
7 = Not Used
8 = Not Used
9 = Free Hoist
Note1: when one of listed motors is selected, Parameters group G1.2.4, G1.2.5 and
G1.2.6 are not viewable. Parameters group G1.2.4, G1.2.5 can be viewed after P1.2.2 is
set back to 1 ‘’free travel’’
P1.2.3 Number of Motors 0 10 pcs The parameter is not active if value 0,1 or 9 in P1.2.2 is selected
G1.2.4 Motor Nominal Values, see note1
Code
Name Min Max Unit Description
P1.2.4.1 Motor Nominal
Frequency
0.00 120.00 Hz Nominal motor frequency (fn) from motor nameplate
P1.2.4.2 Motor Nominal current 0.0 A Disc brake motors:
Number of motors * In (Motor nominal current)
Compact brake motors:
Number of motors * In or
Number of motors * 2,3A, if In<2,3A
DC-current during starting = Motor Nominal current P1.2.4.2. * Start Current P1.2.6.1
DC-current during stoping = Motor Nominal current P1.2.4.2.
