GW-7552 PROFIBUS/MODBUS GATEWAY User Manual (Version 1.40, Apr/2012) PAGE: 64

Step 5:

Set Com Port communication setting of Utility (please refer section 5.2.2
Com Port settings) the same as Com Port setting of GW-7552(please refer
section 4.3 The Configuration of the common parameters)

Step 6:

Click “Communication=>Connect” button in menu.

Figure 64 Communication menu

Step 7:

Module state shows green in the Utility now, it means the connection is
complete.

Figure 65 Display connection state
