GW-7552 PROFIBUS/MODBUS GATEWAY User Manual (Version 1.40, Apr/2012) PAGE: 6
●
Baud Rate：2400/4800/9600/19200/38400/57600/115200 bps
●
Data Format: 7/8 data bits, None/Odd/Even parity bit, 1/2 stop bit
PROFIBUS specs:
●
PROFIBUS interface connector: D-sub 9-pin female
●
Baud Rate: 9.6K/19.2K/45.45K/93.75K/187.5K/500K/1.5M/3M/6M/ 12Mbps
●
Address Setting: 0~126 (set by DIP switch or EEPROM)
Power requirement:
●
Unregulated +10V ~ +30V DC
●
Power reverse protection, Over-Voltage brown-out protection
●
Power consumption 2.5W
Module specs:
●
Dimensions: 119mm X 72mm X 33mm
●
Operating temperature: -25 ~ 75 ºC
●
Storage temperature: -30 ~ 85 ºC
●
Humidity：5 ~ 95%, non-condensing
●
LED Status Indicators(Table 2)
Table 2: LED status indicator
PWR LED
− Shows the power state
− COM Port state: transmit or receive data
ERR LED − Show error state
RUN LED − Show communication state of PROFIBUS
