GW-7552 PROFIBUS/MODBUS GATEWAY User Manual (Version 1.40, Apr/2012) PAGE: 18

PS:

There are two kinds of methods to enable the setting mode of the GW-7552. The user
can change the position of the dip switch or set the control bit (please refer section
4.6.2 Output data area and communication command) to enable the setting mode of
the GW-7552, as shown in table 11.

Table 11 Mode of GW-7552

Mode

SM(control bit)=0

SM(control bit)=1

Dip switch=Normal

operation mode

setting mode

Dip switch =Setting

setting mode

setting mode
