Appendix B
www.bb-elec.com
www.bb-europe.com
42
APPENDIX B: PRODUCT SPECIFICATIONS
GENERAL SPECIFICATIONS
Hardware and
included accessories
Device Serial Server
CD CD with Vlinx Manager software for
Windows 2000, XP (32/64 bit), 2003 Server
(32/64 bit), Vista (32/64 bit), 2008 Server
(32/64 bit), Windows 7 (32/64 bit)
Optional Accessories Cable 232NM9 Null Modem Crossover Cable for
DTE to DTE connection
Rail ERS35 one-meter length of steel 35mm DIN
Rail
Configuration Options Via serial port Using Vlinx Manager via a serial
connection, (press Reset button to enter
Console Mode)
Via network Using Vlinx Manager via a Ethernet
connection
Using a standard web browser such as
Internet Explorer 6.0/7.0 or Firefox 1.5/2.0
Software Vlinx Manager for
serial server
configuration
Windows 2000, XP (32/64 bit), 2003 Server
(32/64 bit), Vista (32/64 bit), 2008 Server
(32/64 bit), Windows 7 (32/64 bit)
Environment Operating
Temperature
-40 to 80 °C (-40 to 176 °F)
Storage Temperature -40 to 85 °C (-40 to 185 °F)
Operating Humidity 10 to 95% non-condensing
Maximum Ambient
Surrounding Air Temp
80 °C
Certifications FCC Part 15 Class A
CE
UL File E222870
UL Class1 Div2 Groups A, B, C, D (HAZLOC) File E245458
TS2
Enclosure Rating IP30
Mounting DIN rail mount (35 mm)
Dimensions
(VESR90x)
1.2 x 3.3 x 4.7 in (3.1 x 8.4 x 11.9 cm)
Dimensions
(VESR92x)
1.2 x 4.3 x 6.2 in (3.1 x 10.9 x 15.7 cm)
Power Supply Voltage Requirements 10 to 48 VDC (58 VDC Maximum)
