Page 13: Led indicators(vesr90x)
Hardware
www.bb-elec.com
www.bb-europe.com
7
VESR9XX SERIAL SERVER HARDWARE
VESR9xx Serial Servers are enclosed in DIN rail mountable enclosures and feature
LED indicators, power, Ethernet and serial connectors and a recessed Mode switch.
PACKAGE CHECKLIST
VESR9xx Serial Servers are shipped with the following items included:
VESR9xx Serial Server Module
Quick Start Guide
CD with User Manual, Quick Start Guide and firmware
VESR9XX SERIAL SERVER ENCLOSURES AND MOUNTING
All VESR9xx Serial Server models are built into similar enclosures. Modules are DIN
rail mountable.
Figure 2. Front View of the VESR922T and VESR902T Serial Server
LED INDICATORS(VESR90X)
VESR9xx Serial Servers have three LED indicators: a Link LED, a Ready LED and two
Serial Port LEDs.
Figure 3. LEDs on 1 and 2 Port Serial Servers
