Setup and Connections

www.bb-elec.com

www.bb-europe.com

17

Figure 15. Ethernet Pass-through Port

VESR9XX SERIAL SERVER CONFIGURATION CONNECTIONS

VESR9xx Serial Servers can be configured over the network or via a serial port.

CONFIGURING THE VESR9XX SERIAL SERVER VIA THE NETWORK
CONNECTION

When configuring via the network, either Vlinx Manager software or the web
interface can be used.

CONFIGURING WITH VLINX MANAGER

VESR9xx Serial Servers can be configured over the network Vlinx Manager software
running on a PC.
To open Vlinx Manager:
