Introduction
www.bb-elec.com
www.bb-europe.com
5
VESR9XX SERIAL SERVER FEATURES
Three series models

VESR9x1-x (single serial port)
 VESR9x2D-x (two serial ports with DB9M)
 VESR9x2T-x (two serial ports with pluggable terminal blocks)
Fiber models available for each of the above series
Ethernet pass through ports are available on VESR92x series models.
Multi-interface serial ports
DB-9M and pluggable terminal block serial port connector options
All ports are software selectable as RS-232, RS-422 or RS-485 2- and 4-wire
Configuration can be done via network or direct serial connection
Slim line DIN rail mountable case
Accepts DC power over a wide voltage range
10/100 Mbps Ethernet with Auto Selection
LAN and WAN Communications
TCP Client or Server, or UDP operation - configurable
Virtual COM port and Paired Mode capabilities
Firmware Upload for future revisions/upgrades
Software Support - Windows 2000, XP (32/64 bit), 2003 Server (32/64 bit), Vista
(32/64 bit), 2008 Server (32/64 bit), Windows 7 (32/64 bit)
Configuration of Ethernet and serial port settings using Vlinx Manager software
VLINX MANAGER CONFIGURATION SOFTWARE
Vlinx Manager configuration software enables you to find connected serial servers,
configure them, upgrade serial server firmware, and save/load configuration files. It
features a graphical user interface (GUI) that is convenient and easy to use. The
software also makes it easy to add and remove virtual COM ports on your computer.
