Introduction
Manual Documentation Number: ESP901-902_5012m Chapter 1 1
B&B Electronics Mfg Co Inc – 707 Dayton Rd - PO Box 1040 - Ottawa IL 61350 - Ph 815-433-5100 - Fax 815-433-5104 – www.bb-elec.com
B&B Electronics Ltd – Westlink Commercial Pk – Oranmore, Galway, Ireland – Ph +353 91-792444 – Fax +353 91-792445 – www.bb-europe.com
C C h h a a p p t t e e r r 1 1 : : I I N N T T R R O O D D U U C C T T I I O O N N
VLINX Models ESP901 and ESP902 Ethernet Serial Servers provide
Ethernet to Serial connections for RS-232, RS-422 or RS-485 devices.
The ESP901 features a single serial port and the ESP902 features two
serial ports. The serial ports can be accessed over a LAN/WAN using
Direct IP Mode , Virtual COM Port , or Paired Mode connections. The
10/100 Mbps Ethernet connection auto-selects 10BaseT or 100BaseTX
and indicates the type of connection with a bi-color link light.
Figure 1. VLINX ESP901 and ESP902 Ethernet Serial Servers
