Using ESP Manager
Manual Documentation Number: ESP901-902_5012m Chapter 4 25
B&B Electronics Mfg Co Inc – 707 Dayton Rd - PO Box 1040 - Ottawa IL 61350 - Ph 815-433-5100 - Fax 815-433-5104 – www.bb-elec.com
B&B Electronics Ltd – Westlink Commercial Pk – Oranmore, Galway, Ireland – Ph +353 91-792444 – Fax +353 91-792445 – www.bb-europe.com
Exit

Allows you to Exit the ESP Manager program
Help

Accesses the About vcomui dialogue box, which indicates the
software version number
Server Icons Pane
Firmware Upgrade , Virtual COM Configuration , Searching Server ,
Uninstall Virtual COM and Monitor Port Status can also be selected
using icons located in the left window.
Serial Server / Virtual COM Lists
To make management of lists of serial server easier, lists can be sorted
by clicking on any tab heading. Scrolling bars facilitate scrolling
through long lists.
Serial Server List

Server Name - Displays the name of the Serial Server . The name
is listed once for each port.

IP Address - Displays the IP Address for the Serial Server . All
ports in a Serial Server have the same the same IP address.

Protocol - Displays the currently selected TCP or UDP mode for
the Serial Server .

Port - Displays the port number for each Serial Server port.

COM Name - Displays the name of the computer COM port
mapped to each Serial Server port. If no computer port has been
mapped it displays Not mapped.

Status - The Status indicates the mapped virtual COM port
condition.
o
Not Connected is shown when a program does not have the
port Open.
o
Connected is shown when that mapped port is Open for use.
Virtual COM List

COM Name - Displays the number of the COM port mapped to
each Serial Server port.

IP Address - Displays the IP Address for the Serial Server . All
ports in a Serial Server have the same IP address.

Protocol - Displays the currently selected TCP or UDP mode for
the Serial Server .
