Introduction
6 Chapter 1 Manual Documentation Number: ESP901-902_5012m
B&B Electronics Mfg Co Inc – 707 Dayton Rd - PO Box 1040 - Ottawa IL 61350 - Ph 815-433-5100 - Fax 815-433-5104 – www.bb-elec.com
B&B Electronics Ltd – Westlink Commercial Pk – Oranmore, Galway, Ireland – Ph +353 91-792444 – Fax +353 91-792445 – www.bb-europe.com
Software Installation
Using the CD included with the Serial Server , install the VLINX ESP
Manager software on the configuring computer.
Serial Server Configuration
Step 1: Open the ESP Manager software. It will automatically search
for any reachable (ESP90x) Serial Servers . A list of all Serial
Servers connected to the LAN will appear in the Serial
Server List window.
Step 2: Double click the desired Serial Server port on the list to bring
up the Server Properties configuration screen.
Figure 3. The Server Properties Window
Step 3: Change the Server Properties as required.

Enable DHCP to allow the Serial Server to generate its
own IP address
OR

Obtain appropriate static IP , Netmask and Gateway
addresses from your Network Administrator
(recommended)

Set the Serial Port Mode property to RS-232 to match the
serial device connected to the Serial Server .

Set Baud Rate , Data/Parity/Stop , and Flow Control to
match the configuration of the serial device connected to
the
Serial Server port
Step 4: When the parameters have been set, click Update . Following
the prompts in the dialogue boxes, Restart the Serial Server
and Search all reachable servers again.
