Using ESP Manager
24 Chapter 4 Manual Documentation Number: ESP901-902_5012m
B&B Electronics Mfg Co Inc – 707 Dayton Rd - PO Box 1040 - Ottawa IL 61350 - Ph 815-433-5100 - Fax 815-433-5104 – www.bb-elec.com
B&B Electronics Ltd – Westlink Commercial Pk – Oranmore, Galway, Ireland – Ph +353 91-792444 – Fax +353 91-792445 – www.bb-europe.com

Searching Server - Searches for Serial Servers on the network
and brings back configuration information that will be displayed in
the
Server Properties window.

Uninstall Virtual COM - Allows virtual COM ports to be
uninstalled from the ESP Manager window.

Monitor Port Status - Brings up a screen that displays the
following information associated with the selected serial port:
o Serial TX: Displays the number of bytes of data sent to
the serial device since the IP connection was established.
o Serial RX: Displays the number of bytes of data received
from the connected serial device since the IP connection
was established.
o DTR/RTS: The
DTR/RTS Port Status indicator displays
the current logic state of the DTR and RTS hardware
handshake (output) lines for the selected
Serial Server
port (1 = asserted, 0 = not asserted).
o DCD/DSR/CTS: The
DCD/DSR/CTS Port Status
indicator displays the current logic state being received on
the DCD, DSR and CTS hardware handshake (input) lines
for the selected
Serial Server port (1 = asserted, 0 = not
asserted)
o Status: Indicates whether the client software has made a
connection with the Serial Server.
o IP Address: Displays the IP address of the connected
client when there is a client connection

Save Configuration File - Allows the user to save the current
configuration information to a file with a .vcom extension.

Load Configuration File - Allows the user to load a configuration
file.
View
Provides three viewing options for the ESP Manager screen:

Toolbar – allows the toolbar (directly under the menu bar) to be
viewable or hidden

Status Bar – allows the Status Bar (at the bottom of the screen to
be viewable or hidden

Split – allows the position of the split between the Icons pane and
the Virtual COM List / Serial Server List panes to be dragged
horizontally using the mouse
