Upgrade Mode
Manual Documentation Number: ESP901-902_5012m
Chapter 8
53
B&B Electronics Mfg Co Inc – 707 Dayton Rd - PO Box 1040 - Ottawa IL 61350 - Ph 815-433-5100 - Fax 815-433-5104 – www.bb-elec.com
B&B Electronics Ltd – Westlink Commercial Pk – Oranmore, Galway, Ireland – Ph +353 91-792444 – Fax +353 91-792445 – www.bb-europe.com
C
C
h
h
a
a
p
p
t
t
e
e
r
r
8
8
:
:
U
U
P
P
G
G
R
R
A
A
D
D
I
I
N
N
G
G
T
T
H
H
E
E
S
S
E
E
R
R
I
I
A
A
L
L
S
S
E
E
R
R
V
V
E
E
R
R
F
F
I
I
R
R
M
M
W
W
A
A
R
R
E
E
New
Serial Server
firmware updates may become available through
the B&B Electronics website for installation into the server. The
firmware can be uploaded using either a virtual COM port connection
or hardware COM port connection.
Downloading the Firmware
Make a folder to receive the firmware file. Download the compressed
software file from the B&B Electronics website. Unzip or expand the
file into the (.hex) format so it will be ready to upload to the
Serial
Server
.
Upgrading Via ESP Manager
The
ESP Manager
software can upload new firmware to the server
using a direct PC connection via the ESP901 serial port, ESP902 Port
1, or using a virtual COM port.
N
N
o
o
t
t
e
e
:
:
If connecting directly to a computer serial port, use a null modem
cable between the Computer RS-232 port and the ESP901 serial port
or ESP902 Port 1.
Preparing the Software
Step 1: In the
ESP Manager
Serial Server List
window, double click
the server to be upgraded. The
Server Properties
window will
appear.
Step 2: If using a direct connection to upload the firmware to the
Serial
Server
, set the baud rate to
115200
for the fastest possible
upload.
Step 3: Set the
Serial Port
field to upgrade and click the
Update
button. (Ensure that the DIP switches on the ESP901 or
ESP902 are all in the OFF position.)
