20
9122B–AUTO–10/08
ATA6833/ATA6834 [Preliminary]
8.4
Output peak current at pins
Lx switched to LOW
V
Lx
= 3V I
LxL
–100 mA D
8.5
Output peak current at pins
Lx switched to HIGH
V
Lx
= 3V I
LxH
100 mA D
8.6
Sink resistance between Lx
and GND Lx to
GND
R
Lxsink
45 75 115 k
Ω
A
8.7
ON-resistance of sink stage
of pins Hx
V
Sx
= 0V R
DSON_HxL
20
Ω
A
8.8
ON-resistance of source
stage of pins Hx V
Sx
= V
VBAT
I
Hx
= 100 mA
R
DSON_HxH
20
Ω
A
8.9
Output peak current at pins
Hx (switched from low to
high
V
Hx
– V
Sx
= 0V;
V
VBAT
= 7V – 20V
C = 10 nF
R = 1
Ω
I
HxH,
–200 mA C
8.10
Output peak current at pins
Hx (switched from high to
low)
V
Hx
– V
Sx
= 10V;
V
VBAT
= 7 – 20V
C = 10 nF
R = 1
Ω
I
HxL
200 mA C
8.11
Output peak current at pins
Hx (switched from low to
high
V
Lx
= 0V;
V
VBAT
= 7 – 20V
C = 10 nF
R = 1
Ω
I
LxH,
–200 mA C
8.12
Output peak current at pins
Hx (switched from high to
low)
V
LX
= 10V;
V
VBAT
= 7 – 20V
C = 10 nF
R = 1
Ω
I
LxL
200 mA C
8.13
Output voltage low level
pins Hx V
Sx
= 0V
I
Hx
= 1 mA
V
HxL
0.3 V A
8.14
Output voltage high level
pins Hx
I
Hx
= –100 µA V
HxHstat
V
VCPOUT
– 1V
V
VCPOUT
V A
8.15
Sink resistance between Hx
and Sx
R
Hxsink
45 75 115 k
Ω
A
8.16
Sink resistance between Sx
and GND Sx to
GND
R
Sxsink
1 M
Ω
D
Dynamic Parameters
8.17
Propagation delay time,
low-side driver from high to
low
t
LxHL
0.9 µs A
8.18
Propagation delay time,
low-side driver from low to
high
t
LxLH
0.9 µs A
8.19 Fall time low-side driver
V
VBAT
= 13.5V
C
Gx
= 5 nF
t
Lxf
TBD µs A
8.20 Rise time low-side driver
V
VBAT
= 13.5V
C
Gx
= 5 nF
t
Lxr
TBD µs A
8. Electrical Characteristics (Continued)
All parameters given are valid for 5.5V
≤
V
VBAT
≤
18V and for –40°C
≤
T
J
≤
150°C (200°C) unless stated otherwise. All values refer to PIN
GND. [xxx] Values for the ATA6834.
No. Parameters Test Conditions Pin Symbol Min. Typ. Max. Unit Type*
*) Type means: A = 100% tested, B = 100% correlation tested, C = Characterized on samples, D = Design parameter
