14
9122B–AUTO–10/08
ATA6833/ATA6834 [Preliminary]
4. Absolute Maximum Ratings
Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. This is a stress rating
only and functional operation of the device at these or any other conditions beyond those indicated in the operational sections of this
specification is not implied. Exposure to absolute maximum rating conditions for extended periods may affect device reliability.
All voltages are referenced to pin GND. [xxx] Values for the ATA6834.
Parameters Pin Symbol Min. Max. Unit
Input voltage PGND V
PGND
–0.3 +0.3 V
Negative input current VBAT IVBAT TBD TBD mA
Negative input current PBAT IPBAT TBD TBD mA
Supply voltage VBAT V
VBAT
–0.3 +40 (500 ms) V
Supply voltage PBAT V
PBAT
–0.3 +40 (500 ms) V
Logic output voltage
/RESET, DG1,
DG2, DG3, RXD
V
/RESET
, V
DG1
, V
DG2
,
V
DG3
, V
RXD
–0.3 V
VCC
+ 0.3 V
Logic input voltage
IL1-3, IH1-3, WD,
WDD, EN1, TXD
V
IL1-3
, V
IH1-3
, V
WD
,
V
EN1
, V
TXD
–0.3 V
VCC
+ 0.3 V
Output voltage VINT, VCC V
INT
, V
VVCC
–0.3 +5.5 V
Analog input voltage RWD, CC V
RWD
–0.3 V
VCC
+ 0.3 V
Digital input voltage EN2 V
EN2
–0.3 V
VBAT
+ 0.3 V
Digital input voltage VMODE V
VMODE
–0.3 V
VINT
+ 0.3 V
Output voltage VG V
VG
–0.3 +16 V
Input voltage LIN V
VLIN
–27 V
VBAT
+ 2 V
Output voltage S1, S2, S3 V
S1
, V
S2
, V
S3
–6 +30 V
Output voltage L1, L2, L3 V
L1
, V
L2
, V
L3
V
PGND
– 0.3 V
VG
+ 0.3 V
Output voltage H1, H2, L3 V
H1
, V
H2
, V
H3
V
S1, 2, 3
– 1 V
S1, 2, 3
+ 16 V
Charge pump CPLO1, 2 V
CPLO1
, V
CPLO2
–0.3 V
PBAT
+ 0.3 V
Charge pump CPHI1, 2 V
CPHO1
, V
CPHO2
–0.3 V
CPOUT
+ 0.3 V
Output voltage CPOUT V
CPOUT
–0.3 +40 V
Output voltage VBATSW V
VBATSW
–0.3 V
VBAT
+ 0.3 V
Storage temperature T
Storage
–55 +150 °C
5. Thermal Resistance
Parameters Symbol Value Unit
Thermal resistance junction to heat slug R
thjc
< 5 K/W
Thermal resistance junction to ambient when heat slug
is soldered to PCB
R
thja
25 K/W
