- result code indication reporting for SMS-DELIVER
0 - No SMS-DELIVER indications are routed to the TE.
1 - If SMS-DELIVER is stored into ME/TA, indication of the memory location is routed to the TE using
the following unsolicited result code:
+CMTI: ,
where:
- memory storage where the new message is stored
"SM"
"ME"
- location on the memory where SM is stored.
2 - SMS-DELIVERs (except class 2 messages and messages in the message waiting indication
group) are routed directly to the TE using the following unsolicited result code:
(PDU Mode)
+CMT: ,
where:
- alphanumeric representation of originator/destination number corresponding to the
entry found in MT phonebook
- PDU length
- PDU message
(TEXT Mode)
+CMT:,,[,,,,,
,,] (the information written in italics will be present
depending on +CSDH last setting)
where:
- originating address, string type converted in the currently selected character set (see
+CSCS)
- alphanumeric representation of ; used character set should be the one selected
with either command +CSCS or @CSCS.
- arrival time of the message to the SC
, - type of number or :
129 - number in national format
145 - number in international format (contains the "+")
- first octet of GSM 03.40
- Protocol Identifier
- Data Coding Scheme
- Service Centre address, string type, converted in the currently selected character set
(see +CSCS)
- text length
- TP-User-Data
Class 2 messages and messages in the message waiting indication group (stored message)
result in indication as defined in =1.
3 - Class 3 SMS-DELIVERs are routed directly to TE using unsolicited result codes defined in
=2. Messages of other data coding schemes result in indication as defined in =1.
