AT49F512

5

AC Read Waveforms

(1)(2)(3)(4)

Notes:

1.

CE may be delayed up to t

ACC

- t

CE

after the address transition without impact on t

ACC

.

2.

OE may be delayed up to t

CE

- t

OE

, after the falling edge of CE without impact on t

CE

or by t

ACC

- t

OE

after an address change

without impact on t

ACC

.

3.

t

DF

is specified from OE or CE whichever occurs first (C

L

= 5 pF).

4.

This parameter is characterized and is not 100% tested.

Input Test Waveforms and
Measurement Level

t

R

, t

F

< 5 ns

Output Test Load

Note:

1. This parameter is characterized and is not 100% tested.

AC Read Characteristics

Symbol

Parameter

AT49F512-50

AT49F512-70

AT49F512-90

Units

Min

Max

Min

Max

Min

Max

t

ACC

Address to Output Delay

50

70

90

ns

t

CE

(1)

CE to Output Delay

50

70

90

ns

t

OE

(2)

OE to Output Delay

30

35

0

40

ns

t

DF

(3)(4)

CE or OE to Output Float

0

25

0

25

0

25

ns

t

OH

Output Hold from OE, CE or
Address, whichever occurred first

0

0

0

ns

Pin Capacitance

f = 1 MHz, T= 25

°

C

(1)

Symbol

Typ

Max

Units

Conditions

C

IN

4

6

pF

V

IN

= 0V

C

OUT

8

12

pF

V

OUT

= 0V
