RC2100
 2005 Radiocrafts AS RC2100 Data Sheet (rev. 1.0) Page 10 of 22
CRC_MODE 0x15 0: FCS only
2: CRC16
0x02 (2) Set to 0 in transparent
mode.
Reserved 0x16 0x00 (0)
Reserved 0x17 0x00 (0)
Reserved 0x18 0x00 (0)
UNIQUE_ID Unique ID
(UID)
0x19 0-255 0x01 (1)
SYSTEM_ID System (net or
family) ID (SID)
0x1A 0x00-0xFF
(0-255)
0x01 (1)
Reserved 0x1B 0x0A (10)
Reserved 0x1C 0x0A (10)
Reserved 0x1D 0x0A (10)
Reserved 0x1E 0x0A (10)
Reserved 0x1F 0x01 (1)
Reserved 0x20 0x01 (1)
UNIQUE_
DESTINATION_ID
Default
destination
address
0x21 0x01 (1) Set to same as
BROADCAST_ADDRES
S when broadcasting
using address mode 2.
SYSTEM_
DESTINATION_ID
Default
destination
address
0x22 0x01 (1) Used in address mode 9
only.
Reserved 0x23 0x00 (0)
Reserved 0x24 0x00 (0)
Reserved 0x24 0x00 (0)
Reserved 0x26 0x00 (0)
Reserved 0x27 0x04 (4)
BROADCAST_
ADDRESS
Broadcast
address
0x28 0x00-0xFF
(0-255)
0xFF
(255)
All nodes accept
messages to this address
in address mode 2.
Reserved 0x29 0x08 (8)
Reserved 0x2A 0x00 (0)
Reserved 0x2B 0x00 (0)
Reserved 0x2C 0x00 (0)
Reserved 0x2D 0x00 (0)
Reserved 0x2E 0x00 (0)
Reserved 0x2F 0x00 (0)
Data and configuration interface, UART Serial Port
UART_BAUD_RATE Baud rate 0x30 0x00: Not used
0x01: 600
0x02: 1200
0x03: 2400
0x04. 4800
0x05: 9600
0x06: 19200
0x06 (6) BE CAREFUL
IFCHANGING AS HOST
MAY LOOSE CONTACT
WITH MODULE!
Does not take effect until
module is re-booted /
reset.
Reserved 0x31 0x08 (8)
Reserved 0x32 0x00 (0)
Reserved 0x33 0x01 (1)
Reserved 0x34 0x05 (5)
UART_FLOW_CTRL UART flow
control
0x35 0: None
1:CTS only
3:CTS/RTS
4:RXTX(RS485)
0x00 (0) Set to 0 in transparent
mode.
DATA_INTERFACE Data interface 0x36 0x00: UART
using RXD and
TXD
0x01:
Synchronous
interface (SDA,
SCL) using
RXEN and TXEN
for direction
control
0x00 (0) When buffered mode is
selected for MAC_MODE
use UART. For flow
control, see above.
When transparent mode
is selected for
MAC_MODE use
Synchronous interface.
Reserved 0x37 0x01 (1)
Reserved 0x38 0x2B (43)
Reserved 0x39 0x00 (0)
Reserved 0x3A 0x01 (1)
Exit from memory 0xFF No argument To exit from configuration
