T89C51AC2

Rev. B – 19-Dec-01

Table 22. TH0 Register

TH0 (S:8Ch)
Timer 0 High Byte Register

Reset Value= 0000 0000b

Table 23. TL0 Register

TL0 (S:8Ah)
Timer 0 Low Byte Register

Reset Value= 0000 0000b

Table 24. TH1 Register

TH1 (S:8Dh)
Timer 1 High Byte Register

Reset Value= 0000 0000b

7

6

5

4

3

2

1

0

Bit

Number

Bit

Mnemonic

Description

7:0

High Byte of Timer 0.

7

6

5

4

3

2

1

0

Bit

Number

Bit

Mnemonic

Description

7:0

Low Byte of Timer 0.

7

6

5

4

3

2

1

0

Bit

Number

Bit

Mnemonic

Description

7:0

High Byte of Timer 1.
