MAX16010–MAX16014
Ultra-Small, Overvoltage Protection/
Detection Circuits
2 _______________________________________________________________________________________
ABSOLUTE MAXIMUM RATINGS
ELECTRICAL CHARACTERISTICS
(V
CC
= 14V, T
A
= -40°C to +125°C, unless otherwise noted. Typical values are at T
A
= +25°C.) (Note 1)
Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only, and functional
operation of the device at these or any other conditions beyond those indicated in the operational sections of the specifications is not implied. Exposure to
absolute maximum rating conditions for extended periods may affect device reliability.
(All pins referenced to GND, unless otherwise noted.)
V
CC .........................................................................-0.3V to +80V
EN, EN, LOGIC...........................................-0.3V to (V CC + 0.3V)
INA+, INB-, IN+, IN-, REF, SET ..............................-0.3V to +12V
OUTA, OUTB, OUT.................................................-0.3V to +80V
GATE1, GATE2 to V
CC ...........................................-12V to +0.3V
GATE1, GATE2...........................................-0.3V to (V CC + 0.3V)
Current Sink/Source (all pins) .............................................50mA
Continuous Power Dissipation (T A = +70°C)
6-Pin TDFN (derate 18.2mW/°C above +70°C) .........1455mW
8-Pin TDFN (derate 18.2mW/°C above +70°C) .........1455mW
Operating Temperature Range .........................-40°C to +125°C
Maximum Junction Temperature .....................................+150°C
Storage Temperature Range .............................-60°C to +150°C
Lead Temperature (soldering, 10s) .................................+300°C
PARAMETER SYMBOL CONDITIONS MIN TYP MAX UNITS
Supply Voltage Range V CC 5.5 72.0 V
V CC = 12V 20 30
Input Supply Current I CC No load
V
CC
= 48V 25 40
µA
V CC Undervoltage Lockout V UVLO
V CC rising, part enabled, V INA+ = 2V, OUTA
deasserted (MAX16010/MAX16011),
V
IN = 2V, V OUT deasserted (MAX16012),
V SET = 0V, GATE2 = V CLMP (MAX16013/
MAX16014)
4.75 5 5.25 V
V TH+ 1.215 1.245 1.265
0.5% hysteresis, MAX16010/MAX16011 1.21 1.223 1.26
5.0% hysteresis, MAX16010/MAX16011/
MAX16013/MAX16014
1.15 1.18 1.21
INA+/INB-/SET Threshold Voltage
V TH-
7.5% hysteresis MAX16010/MAX16011 1.12 1.15 1.18
V
MAX16010TAA/MAX16011TAA 0.5
MAX16010TAB/MAX16011TAB/
MAX16013/MAX16014
5.0 Threshold-Voltage Hysteresis
MAX16010TAC/MAX16011TAC 7.5
%
SET/IN_ Input Current SET/IN_ = 2V -100 +100 nA
IN_ Operating Voltage Range 0 4 V
Startup Response Time t START V CC rising from 0 to 5.5V 100 µs
IN_ to OUT/SET to GATE2
Propagation Delay
t PROP
IN_/SET rising from (V TH - 100mV) to
(V TH + 100mV) or falling from (V TH +
100mV) to (V TH - 100mV) (no load)
2 µs
V CC
≥ 5.5V, I
SINK = 3.2mA 0.4 V
OUT_ Output-Voltage Low V OL
V CC
≥ 2.8V, I
SINK = 100µA 0.4 V
OUT_ Leakage Current I LEAK OUT_ = 72V 500 nA
