MAX16010–MAX16014
Ultra-Small, Overvoltage Protection/
Detection Circuits
______________________________________________________________________________________ 11
Chip Information
PROCESS: BiCMOS
8 7 6 5
1 2 3 4
INA+ OUTA EN INB-
V CC GND EN OUTB
TOP VIEW
MAX16010
TDFN (3mm x 3mm)
8 7 6 5
1 2 3 4
INA+ OUTA EN INB-
V CC GND LOGIC OUTB
MAX16011
TDFN (3mm x 3mm)
6
IN+
5
REF
4
IN-
1
V CC
2
GND
3
OUT
MAX16012
TDFN (3mm x 3mm)
6
GATE1
5
EN
4
SET
1
V CC
2
GND
3
GATE2
MAX16013
MAX16014
TDFN (3mm x 3mm)
Pin Configurations
