45
Digital Inputs and Outputs
Connectors:
Formats:
Output Dither:
Word Clock Input:
Sample Rates:
Processing Delay:
Frequency Response DIO:
Processing Resolution:
By-pass on AES (optional):
Analog Inputs
Connectors:
Impedance:
Max. Input Level:
Min. Input Level (for 0 dBFS):
Sensitivity:
A to D Conversion:
D to Av Conversion:
A to D Delay:
Dynamic Range:
THD:
Frequency Response:
Crosstalk:
Analog Outputs
Connectors:
Impedance:
Max. Output Level:
Full Scale Output Range:
D to A Conversion:
D to A Delay:
Dynamic Range:
THD:
Frequency Response:
Crosstalk:
XLR (AES/EBU)
RCA Phono (S/PDIF)
Optical (Tos-link, ADAT)
AES/EBU (24 bit),
S/PDIF (24 bit), EIAJ CP-340, IEC 958,
EIAJ Optical (Tos-link),
ADAT Lite pipe (24 bit)
HPF/TPDF dither 16-24 bit, independent
dithered output
RCA Phono, 75 ohm, 0.6 to 10 Vpp
44.1 kHz, 48 kHz
0.2 ms @ 48 kHz
DC to 23.9 kHz ± 0.01 dB @ 48 kHz
48 bit fixed point
Through relay
XLR balanced (pin 2 hot)
20 Kohm
+22 dBu (balanced)
-10 dBu
@ 12 dB headroom: -22 dBu to +10 dBu
24 bit (1 bit, 128 times oversampling)
24 bit (1 bit, 128 times oversampling)
0.8 ms @ 48 kHz
>103 dB (unweighted, BW = 22 kHz),
>106 dB(A)
-95 dB (0,0018 %) @ 1 kHz, -6 dBFS (FS
@ +16 dBu)
10 Hz to 20 kHz : +0/-0.2 dB @ 48 kHz
<-80 dB, 10 Hz to 20 kHz
typical –100 dB @ 1 kHz
XLR balanced (pin 2 hot)
100 ohm (active transformer)
+22 dBu (balanced)
-10 dBu to +22 dBu
24 bit (6.144 MHz delta sigma
@ 48/96 kHz)
0.57 ms @ 48 kHz
>+100 dB (unweighted, BW = 22KHz),
>+104 dB(A)
-82 dB (0.008 %) @ 1 kHz, -6 dBFS (FS
@ +16 dBu)
10 Hz to 20 kHz : +0/-0.5 dB @ 48 kHz
<-60 dB, 10 Hz to 20 kHz
typical –90 dB @ 1 kHz
EMC
Complies with:
Safety
Certified to:
Environment
Operating Temperature:
Storage Temperature:
Humidity:
PCMCIA Interface
Connector:
Standards:
Card Format:
Control Interface
COM:
USB:
General
Finish:
Display:
Dimensions:
Weight:
Mains Voltage:
Power Consumption:
Backup Battery Life:
Warranty
Parts and labor:
EN 55103-1 and EN 55103-2
FCC part 15, Class B
CISPR 22, Class B
IEC/EN/UL/CSA 60065, CSA FILE# 108093
32° F to 122° F (0° C to 50° C)
-22° F to 167° F (-30° C to 70° C)
Max. 90 % non-condensing
PC Card, 68 pin type 1 cards
PCMCIA 2.0, JEIDA 4.0
Supports up to 2 MB SRAM
In/Out/Thru: 5 Pin DIN
USB 1.1, cable included
Anodized aluminum front
Plated and painted steel chassis
56 x 128 dot graphic LCD
19” x 1.75” x 8.2” (483 x 44 x 208 mm)
5.2 lb. (2.35 kg)
100 to 240 VAC, 50 to 60 Hz (auto-select)
<20 W
>10 years
5 year
Technical specifications are subject to change
without notice.
TECHNICAL SPECIfICATIONS
