31
LM2 & TC ICON
or changing the Time Reference, resets the meter and
descriptor history.
Low Level Below
Determines where the shift between green and blue
happens in the outer ring. It indicates to the engineer that
level is now at risk of being below the noise floor.
Alert Indicator
Range: Off/Stereo Integrity
The Alert indicator is located on the Radar page and
indicates suspected lack of stereo integrity based on
measuring the difference of left/right outputs. If an
average difference of 3 dB or more between left and right
channels is meassured over a prolonged time, the LED
is lit.
More alert functions may become available with new
versions of LM2 software
Peak Indicator
This parameter sets at which level the peak indicator will
be invoked.
The remaining parameters are described earlier in this
manual.
