Installing the 9400-Series Card Into a Frame Slot

2-6

9400-SERIES PRODUCT MANUAL

9400S-OM (V1.1)

Note:

A Rear I/O Module is required before cabling can be connected. Refer to
Installing a Rear I/O Module (p. 2-3) for rear I/O module installation proce-
dure.

CAUTION

If required, make certain Rear I/O Module(s) is installed before installing the
card into the frame slot. Damage to card and/or Rear I/O Module can occur if
module installation is attempted with card already installed in slot.

Note:

Check the packaging in which the card was shipped for any extra items such
as a Rear I/O Module connection label. In some cases, this label is shipped
with the card and to be installed on the Rear I/O connector bank correspond-
ing to the slot location of the card.

Install the card into a frame slot as follows:

1.

Determine the slot in which the card is to be installed.

2.

Open the frame front access panel.

3.

Remove an protective caps on card fiber optic module(s).

4.

While holding the card by the card edges, align the card such that the
plastic ejector tab is on the bottom.

5.

Align the card with the top and bottom guides of the slot in which the
card is being installed.

6.

Gradually slide the card into the slot. When resistance is noticed, gently
continue pushing the card until its rear printed circuit edge terminals
engage fully into the rear I/O module mating connector.

An audible “click” is heard when the card fiber optic module(s) mates
with the blindmate adapter on the rear module.

CAUTION

If card resists fully engaging in rear I/O module mating connector, check for
alignment and proper insertion in slot tracks. Damage to card and/or rear I/O
module may occur if improper card insertion is attempted.

7.

Verify that the card is fully engaged in rear I/O module mating
connector.

8.

Close the frame front access panel.

9.

Connect BNC cables in accordance with the rear I/O module installed.

10.

Connect fiber connections in accordance with the rear I/O module
installed. Remove the dust cap from the fiber ports on the rear I/O
module and insert cable into transceiver module.

11.

Repeat steps 1 through 10 for other 9400-series cards.
