9400S-OM (V1.1) 9400-SERIES PRODUCT MANUAL 1-11
Introduction
Technical Specifications
9401 thru 9404 (Tx Card) I/O
Specifications: Input Type:
BNC, 75 Ω
Input/Output Loop Return Loss:
>15 dB up to 1.5 GHz
>10 dB up to 3 GHz
Transmitter Wavelength:
1310 nm Single Mode
Optical Power:
-5 dBm to 0 dBm
Laser Power Range:
Laser Class 1
Added Jitter:
<0.03 UI under 1 MHz
Output Type:
Fiber LC, ST, SC, or FC
9401 thru 9404 (Rx Card) I/O
Specifications: Input Type:
Fiber LC, ST, SC, or FC
Wavelength:
1100 to 1600nm
Optical Sensitivity
Pathological 3Gbps: -18 dBm
Pathological HD-SDI: -20 dBm
Output Type:
BNC, 75
Output Return Loss:
>15 dB up to 1.5 GHz
>10 dB up to 3 GHz
Added Jitter:
<0.03 UI under 1 MHz
Output Type:
BNC, 75
Ω
Table 1-1 Technical Specifications — continued
Item Characteristic
