Introduction
9400-series Functional Description
Note: If network remote control is to be used for the frame and the frame has not yet
been set up for remote control, Cobalt ® reference guide Remote Control
User Guide (PN 9000RCS-RM) provides thorough information and
step-by-step instructions for setting up network remote control of
COMPASS™ cards using DashBoard™. (Cobalt
® OGCP-9000 and
OGCP-9000/CC Remote Control Panel product manuals have complete
instructions for setting up remote control using a Remote Control Panel.)
Download a copy of this guide by clicking on the Support>Documents>
Reference Guides link at www.cobaltdigital.com and then select DashBoard
Remote Control Setup Guide as a download, or contact Cobalt
® as listed in
Contact Cobalt Digital Inc. (p. 1-13).
9400-series Rear I/O Modules
The 9400-series physically interfaces to system video connections at the rear
of its frame using a Rear I/O Module.
All inputs and outputs shown in the 9400-series Functional Block Diagram
(Figures 1-1 and 1-2) enter and exit the card via the card edge backplane
connector. The Rear I/O Module breaks out the 9400-series card edge
connections and exposes the fiber transceiver subassemblies to connectors
that interface with other components and systems in the signal chain. Various
Rear I/O Modules are available for various fiber connection formats. See
“Installation”, Chapter 2 for Rear I/O Module connections.
