9400S-OM (V1.1) 9400-SERIES PRODUCT MANUAL 2-1
Chapter 2
Chapter 2
Installation and Setup
Overview
This chapter contains the following information:
• Setting Card Switches (p. 2-1)
• Installing the 9400-Series Card Into a Frame Slot (p. 2-5)
• Installing a Rear I/O Module (p. 2-3)
• Setting Up 9400-Series Network Remote Control (p. 2-7)
Setting Card Switches
Note: • If using DashBoard™ or other network remote control, disregard this
section. Default switch positions allow remote control operation of all
functions.
• If card-edge controls described here are set to card-edge (instead of
DashBoard™), DashBoard™ or other network remote control will be locked
out. Default positions allow DashBoard™ remote control. Do not change
settings here unless card-edge control of these functions is desired.
(See Figure 2-1.) For each channel, card-edge switches allow setting channel
Auto Mute and Reclocker Bypass either on or off manually (instead of via
DashBoard™ remote control). The default switch positions allow remote
control.
If the card is intended to handle signals that are not recognized SMPTE
signals and rates, it is recommended that auto-mute and reclock be bypassed
to prevent the signals from inadvertently being rejected as noise.
These functions can be enabled or disabled using DashBoard™ or the
card-edge switches described here.
• If DashBoard™ remote control of auto-mute/reclock enable/bypass is
to be used, leave the switches in the default settings and skip to
Installing a Rear I/O Module (p. 2-3). Then use DashBoard™ to
configure the Auto Mute and Reclocker settings as described in
Chapter 3, Operating Instructions.
• If DashBoard™ remote control of auto-mute/reclock enable/bypass is
not to be used and manual local control is desired, set each of the
switches as described below before installing the card.
